LEGRAND DMX3 Series User Manual

86
DMX
3
8.2 Real dimensions of the device
8.3 Net Weight
DMX
3
2500 DMX
3
4000 DMX
3
6300
Dimensions - fixed version 3P
Width 273 mm 408 mm 797 mm
Depth 354 mm 354 mm 354 mm
Height 419 mm 419 mm 419 mm
Dimensions - fixed version 4P
Width 358 mm 538 mm 1057 mm
Depth 354 mm 354 mm 354 mm
Height 419 mm 419 mm 419 mm
Dimensions - draw-out version 3P
Width 327 mm 425 mm 804 mm
Depth 433 mm 433 mm 433 mm
Height 473 mm 473 mm 473 mm
Dimensions - draw-out version 4P
Width 412 mm 555 mm 1064 mm
Depth 433 mm 433 mm 433 mm
Height 473 mm 473 mm 473 mm
CIRCUIT BREAKERS
Type
DMX
3
2500 DMX
3
4000 DMX
3
6300
Rating (A)
630/800/1000/
1250/1600
(42kA version)
630/800/1000/
1250/1600/
2000/2500
630/800/1000/
1250/1600/2000
2500/3200/4000
5000/6300
Fixed
3P 39 kg 41 kg 59 kg 118 kg
4P 46 kg 48 kg 76 kg 152 kg
Draw-out
3P 73 kg 77 kg 108 kg 225 kg
4P 90 kg 94 kg 137 kg 274 kg
SWITCH DISCONNECTORS
Type
DMX
3
2500 DMX
3
4000 DMX
3
6300
Rating (A)
1250/1600/
2000/2500
1250/1600/2000/
2500/3200/4000
6300
Fixed
3P 39 kg 57 kg 114 kg
4P 45 kg 73 kg 146 kg
Draw-out
3P 75 kg 106 kg 212 kg
4P 91 kg 134 kg 268 kg
