Keor MOD
Installation and maintenance manual
31
The fastening of the neutral and bypass cables on Keor MOD 250 must be done according to the following steps:
1) Fix the second metal bar above the first bar using two hex M8x14 screws. Then fix the plastic support for the cable ties
using M6 torx pan head screws.
2) Fix the cable with cable ties.
