23662_001
a
a Air inlet with lter
23663_001
a
a Air outlet
23156_001
4
4
1
1
4
4
3
3
3
3
2
2
2
2
1
1
1. Loosen the screw.
2. Remove the lter cover with the used lter.
The lter cannot be removed from the lter cover as it is
one part and has to be exchanged together.
3. Insert a new lter cover with lter in both air inlets.
Ensure that both lter covers are inserted correctly.
4. Fasten the screw.
Position of air inlet
and air outlet
Changing the lter of
the air inlet
step-by-step
Care and Transport 29
