The Correct Interpupillary Distance
Setting the eye distance
1. Look into the eyepieces.
2. Hold the eyepieces with both hands. Push
the eyepieces together or separate them
until you see a circular image.
Note for eyeglass wearers
If you wear glasses, fold the eyecups back –
otherwise, fold the eyecups forwards.
The ideal image
The interpupillary distance is correctly
set if you see a single circular image field
when looking at a specimen.
You may need a short time to become familiar
with using the instrument. Not to worry – after
a little while, it will become automatic.
