Gooseneck light guides that
require no support can now
be positioned relative to the
object.
Other types of light guide are
attached to the stereo-
microscope as described
below.
Please note that the universal
light guide on the Leica S8 APO
can only be used with the side-
ways-mounted lamp arms.
On the Leica S4 E, S6 E, S6, S6 T
and S6 D the one-arm universal
light guide can be inserted di-
rectly in the microscope bracket:
Insert the outlet of the light
guide into the port on
the microscope carrier.
One and two arm
Universal light guide
17
Leica L2 User manual – Installation
Light guide ➔ stereomicroscope
