The near-vertical light beam penetrates depressions and
cavities, suppressing the distracting shadows caused by
the presence of microtools.
Secure the lamp housing to
the objective mount of the
stereomicroscope using the
clamping screw.
• The clamping screw should
be at the front and the
light guide connector at the
rear left.
Connect the flexible light
guide to the light source
(see page 18) and to the
lamp housing.
Near-vertical
illuminator
23
Leica L2 User manual – Accessories
