For LS15:
Field Description
Port : Instrument port.
Mini USB Communication is via the mini USB port.
Bluetooth Communication is via Bluetooth.
RS232 Communication is via the serial interface.
Lemo USB Communication is via the LEMO-to-USB port.
Bluetooth: Active Bluetooth sensor is activated.
Inactive Bluetooth sensor is deactivated.
The following elds are active only when Port : RS232 is set.
Baud rate: Speed of data transfer from receiver to device in bits per
second.
1'200, 2'400, 4'800, 9'600, 14'400, 19'200, 38'400,
57'600, 115'200
Data bits: Number of bits in a block of digital data.
7 Data transfer is realised with seven data
bits.
8 Data transfer is realised with eight data bits.
Parity : Even Even parity. Available if data bit is set to 7.
Odd Odd parity. Available if data bit is set to 7.
None No parity. Available if data bit is set to 8.
Endmark : CR/LF The terminator is a carriage return followed
by a line feed.
CR The terminator is a carriage return.
Stop bits: 1 Number of bits at the end of a block of
digital data.
Acknowlge: On Acknowledgement expected from other
device after data transfer received. If no
acknowledgement is returned, an error mes-
sage displays.
Off No acknowledgement expected after data
transfer.
☞
For Mean, Mean S and Median, you only have to
send the acknowledgement character “?” after the
mean/median value is received, not for the indi-
vidual measurement generating this mean/median
value.
When you select Default, the communication parameters are reset to the
Leica RS232 default settings:
•
115200 Baud, 8 Databit, No Parity, CR/LF Endmark, 1 Stopbit.
Leica RS232 Default
Settings
46 Settings
