49Leica RM 2155  Rotary Microtome
15. Accessories
Fig. 49.1
3
2
15.5.4 Knife holder E-TC
The knife holder E-TC is designed for the Leica TC-65
tungsten carbide blades.
Inserting the blade
 Push the knife guard (1) to the middle.
 To insert the blade, relocate the clamping lever (2)
down.
 Carefully insert the tungsten carbide blade (3) from
the side with the shining facet to the front.
 To clamp the blade, relocate the clamping lever (2)
up.
Cleaning
The clamping plate (7) can be removed for cleaning.
 To remove the blade, relocate the clamping lever
(2) down.
 Carefully remove the blade.
 Pull out the clamping lever (2).
 Remove the clamping plate (7).
Only use mild commercial detergents or soap
solution for cleaning!
Do not use solvents that contain acetone and
xylene!
 Clean all components with a damp not a wet cloth.
 Place the clamping plate (7) on the holder ensuring
that the upper edge of the clamping plate and of
the pressure plate (5) are parallel and at the same
height.
 Insert the clamping lever (2) in the hole and relo-
cate it up.
1
1
7
Fig. 49.2
2
5
