MS50/TS50/TM50, Operation
46
Connect USB cable
to computer for the
first time step-by-
step
Step Description
1. Start the computer.
2. Plug the GEV234 or GEV261 cable into the lemo-port on the instrument.
3. Turn on the TPS instrument.
4. Plug the GEV234 or GEV261 cable into the USB port of the computer. The
Found New Hardware Wizard starts up automatically.
5. Check Yes, this time only. Next>.
6. Check Install the software automatically (Recommended). Next>. The
software for Remote NDIS based LGS TS Device will be installed on your
computer
7. Finish.
8. The Found New Hardware Wizard starts up automatically a second time.
9. Check Yes, this time only. Next>.
10. Check Install the software automatically (Recommended). Next>. The
software for LGS TS USB Device will be installed on your computer.
11. Finish.
For PCs with Windows XP operating system:
12. Run the ActiveSync installation program if not already installed.
13. Allow USB connections inside the Connection Settings window of
ActiveSync.
For PCs with Windows Vista or Windows 7/Windows 8 operating system:
14. Windows Mobile Device Center starts up automatically. If does not start
automatically, start Windows Mobile Device Center.
005011_001
2
3
4
