RTJ400 User Guide
Introduction
A
Jig Template, CNC machined, with holes and slots to position the frame,
and precision guides for routing tails, pins & sockets
B
Jig Frame, CNC machined, with pins that fit into template holes & slots
C
Frame Latches, 2, to secure jig frame to jig template
D
Hex Key, 1/8" Ball End
E
Cam-Action Speed-Clamps, 4, for mounting workpieces to jig
F
Blockers, 10, inserted in template guide openings to prevent routing
G
Stop Rod, inserted in template holes to limit cutting depth
H
Sidestops, 2, for mounting workpieces; adjustable for all joint types
I
Bit Depth Gauge, for setting cutting depth on half-blind dovetails
J
Instruction Strips, 5, for quick reference; inserted in jig top
K
Dovetail Bit 120-500, 1/2" x 1/2" x 14º
L
Dovetail Bit 80-500, 1/2" x 13/16" x 8°
M
Straight Bit 143-500, 3/8" x 1-1/4"
N
Straight Bit 160, 1/2" x 1-1/4"
O
Guide Bushing, e10 Elliptical eBush, for perfect joint fit
P
Pin Wrench, to adjust e10 eBush
Q
User Guide, Fully Illustrated
R
Video, Instructional
RTJ400 Jig Features and Parts
See complete list of jig parts in Chapter 14.
You will need:
• A router table that accepts standard
size (1-3/8"OD) guide bushings
Note:
See page 6 for instructions on
fitting the Leigh eBush to your router
table.
