GettingStarted
• First,unpackyourelectricbikecarefully makingsurethatyoudon’tscratchthebikewithsharptoolssuchaspaperknifesor
scissors.
• Keep allpackingmaterial includingthecartonintheunlikelycasethebikehastobere‐packedandshipped.
• Locateallparts:battery,keys,frontwheel,mudguards, charger,seatandseatpost,frontlight,handle‐stem,pedals,tools
andanysmallpartslikenutsorscrewsinsidetheshippingcarton.
• Sometimessmallpartslikenutsorscrewsmaycomelooseduringshippingsobesureand checkthebottomofthecarton
andprotectivewrappingcarefully.PleasenotethateBikes arefragileitems.Althoughweareusingfirstclasscourierservices
andthebikesareprofessionallypackeditmayhappenthattheygetdamagedduringtransit.
• Pleasecheckthebikefordamageandanymissingpartsuponarrivalandletusknowimmediately.Wewillthenworkwith
youonasolutionandshipreplacementpartsassoonaspossible.
Assembly Instructions
• This bicycle hasbeen disassembledfor shipping.To ship the bike, thepedals, frontlight,frontmudguard,seat, front wheel
and sometimes the handlebar maybe loosened or removed.
• Differentpartsofthebikessuchasbrakesandgearsmayneedadjustment.This manualwilllist the steps requiredfor
installation.
• Checkallnutsandboltsonthebike,evenifpartshavealreadybeenassembledbythefactory,tomakesurethattheyare
installedsafely.
• IntheinterestofsafetyItisrecommendedtohavethebikeassembledandadjustedbyabikemechanicandserviced
regularly.
Installationoffrontmudguardandfrontlights
Thispartofforkfacingforward.
(Thetwosocketswiththreadspointing
forwardarenotused.Theyareforinstallation
ofVbrakeswhicharenotneededsincethe
bikeisequippedwithfrontdiscbrakes.)
FixmudguardtoforkhereOnbothsides
Topbolt:firstinsertHeadlight,thenfront
Mudguard,thentightenbolt(referto
additionalpicturebelow)
Brakecallipers(needtofacelefthandside).
Install front light on top part of fork using bolt
(and nut if your model has nut) as shown in
the picture above. The bolt of some forks is
attached to rear facing part of fork.
Connect black wire to the“‐” poleatthe
backofthelight.
Connect redwire tothe “+” pole. Makesurethesmallmetalpinsof
thelightareinsertedinto theendingofthewire.
7
©LeitnerPtyLtd2020
Tip: To turn on the lights push and hold the “+” button on the LCD
display on the handle‐bar until the lights are on. For details please refer
to the section of this manual titled “Operation of your electric bike”.
