EN-16
- Pivot points (A, fig. 21) of the tandem wheels to be greased every
40 working hours.
- Splines and spindle of the height adjustment to be greased every
40 working hours (B, C, fig. 21).
- Lubricate the trail device of the headstock every 40 hours
(fig. 22).
- Grease the cam track inside the rotor with a high grade grease
(Molykote BR2Plus) every 1,000 hectares or once every year.
The cam track can be easily accessed by disassembling one or
more tine arm shafts from the rotor.
- Grease or lubricate all remaining pivot points every 40 working
hours.
21
40h
A
B
C
22
40h
