LELY HIBISCUS 425 - Btechnical Details

EN-20
B TECHNICAL DETAILS
All details are without engagement and may be
altered without prior notice.
HIBISCUS
®
425 455 485
Working width 3.20 - 4.25 m 3.50 - 4.55 m 3.85 - 4.75 m
Transport width 1.95 m 2.20 m 2.35 m
Transport height 2.00 m 2.10 m 3.00 m
Transport length 3.20 / 3.95 m 3.35 / 4.25 m 3.75 / 4.55 m
Diameter of rotor
(incl. tine arms) 3.20 m 3.50 m 3.80 m
Number of tine arms 11 13
Number of tines / tine arm 4 double tines
Swath width 1.10 -1.40 m
Linkage category II
PTO speed 450 - 500 r.p.m., max. 540 r.p.m.
Overload security K32B radial pin
clutch
K33 radial pin clutch
Operating speed max. 12.5 km/h
Tire size 16/6.9-8 6ply 18.5/8.5-8 6 ply
Power required
48 kW
(65 HP)
51 kW
(70 HP)
59 kW
(80 HP)
Weight approx. 730 kg 785 kg 850 kg
Supplement B
