- Check all bolts and nuts for tightness.
Pay particular attention to the bolts which secure the skids and
wear plates (fig. 23).
When tightening loose bolts/nuts the torques listed below should
be applied.
- Convince yourself of the presence and undamaged condition of
all safety decals on the machine (fig. 24).
A (P/N 9.1170.0408.0)
B (P/N 9.1170.0407.6) -2x-
C (P/N 9.1170.0410.2) -2x-
D (P/N 9.1170.0419.4)
E (P/N 9.1170.0420.5)
F1 (P/N 9.1170.0125.4)
F2 (P/N 9.1170.0175.5)
G (P/N 9.1170.0437.1) -3x-
H (P/N 16.61.175) -2x-
M6 M8 M10 M12 M14 M16 M20 M24
Nm 10 25 50 85 135 215 410 710
kgm 1,0 2,5 5,0 8,5 13,5 21,5 41,0 71,0
23
24
A
BC
D
E
FG
H
BC
H
A
B
CD
E
F1
G H
F2
