E-30
E TECHNICAL DETAILS
All details are without engagement and may
be altered without prior notice.
SPLENDIMO
®
280 MC 320 MC
Working width 2,80 m 3,20 m
Transport width 1,35 m
Transport height 3,80 m 4,00 m
Number of discs / knives 7 / 14 8 / 16
Mowing height
as from 30 mm, infinitely adjustable by means of
top link
Swath width approx. 1,2 - 2,8 m 1,4 - 3,0 m
Mowing on slopes up: 20° - down: 20°
PTO output 540 / 1.000 r.p.m. 1.000 r.p.m.
Linkage category II category II / III
Hydraulic connections
- 1 double acting valve
with floating position
(max. oil pressure 21,0 Mpa
(21,0 bar)
- 1 double acting spool
valve
- 1 single acting spool
valve (with floating
position)
(max. oil pressure 21,0 Mpa
(21,0 bar))
Rotor speed 890 or 1.000 r.p.m.
Rotor diameter 50 cm
Rotor width 232 269 cm
Number of flails 102 119
Security K92 slip clutch
Power required
42 kW
(57 HP)
48 kW
(65 HP)
Weight approx. 1.195 kg 1.225 kg
Supplement E
