LELY SPLENDIMO MC Series User Manual

E-25
C HYDRAULIC GROUND PRESSURE RELIEF SYSTEM
C.1 Scheme
Legend:
1 Controlled return valve 8 Gauge
2 Adjustable overpressure valve 9 Ball valve
3 Return valve 10 Double acting ram
4 Adjustable throttle (one way) 11 Throttle (1 way)
5 Ball valve (spring-loaded return) 12 Cam roller valve (3/2)
6 Buffer ram 13 Valve block
7 Accumulator
1
2
3
4
5
6
7
8
9
10
11
12
3
5
5
13
Supplement C

LELY SPLENDIMO MC Series Specifications

General

Brand	LELY
Model	SPLENDIMO MC Series
Category	Lawn Mower
Language	English

Summary

SAFETY INSTRUCTIONS

2 MOUNTING BEHIND THE TRACTOR

4 MACHINE ADJUSTMENTS

4.3 Ground pressure

Adjusting the ground pressure of the mower.

4.3.1 Mechanical ground pressure relief

Using the spring system to adjust ground pressure.

4.3.2 Hydraulic ground pressure relief

Adjusting ground pressure using the hydraulic system.

5 OPERATING THE SPLENDIMO® MC

6 DISMOUNTING FROM THE TRACTOR

7 MAINTENANCE

7.1 Maintenance after operations

7.2 Lubrication

Greasing PTO shafts, bearing blocks, and pivot points.

7.3 Intermittent maintenance

Performing maintenance at specific intervals or based on usage.

7.4 Replacement of knives

Procedure for replacing mower knives, including torque specs.

7.5 Change of oil in gearboxes

7.6 Change of grease in mower elements

Supplement B CONDITIONER ADJUSTMENTS

Supplement C HYDRAULIC GROUND PRESSURE RELIEF SYSTEM

C.2 Adjustment of minimum system pressure

C.3 Trouble shooting
