Technical specifications
Technical specifications
SECTION LEVELS & DATA CONNECTORS
MONO INPUT CHANNEL
sensitivity
from -10 to -60dB
impedance
1.3 kOhms
sensitivity
from +10 to -40dB
impedance
10 kOhms
HPF
75Hz, 18dB/oct
HIGH
±15dB @ 12kHz, SHELVING
HI-MID
±12dB @ 3kHz, PEAKING
LO-MID
±12dB @ 800Hz, PEAKING
LOW
±15dB @ 80Hz, SHELVING
STEREO INPUT CHANNEL
sensitivity
+4dB
impedance
10 kOhms
HIGH
±15dB @ 12kHz, SHELVING
MID
±12dB @ 2.5kHz, PEAKING
LOW
±15dB @ 80Hz, SHELVING
MASTER SECTION
MIX output (balanced)
output level
+4dB /-26dB
Balanced XLR-
M
MIX output (unbalanced)
output level
+4dB
Unbalanced
JACK
MIX B output
output level
+4dB RCA phono
MONO output
output level
+4dB
Balanced XLR-
M
GROUP output
output level
+4dB
Balanced XLR-
M
CONTROL ROOM output
output level
+4dB
Unbalanced
JACK
MONITOR output
output level
+4dB
Unbalanced
JACK
AUX sends
output level
+4dB
Unbalanced
JACK
AUX return
sensitivity
-10dB
Unbalanced
JACK
IN
-10dB
OUT
+4dB
inimum impedance
200 Ohms
output level
2x160mW
DSP
A/D converters
bit
18
D/A converters
bit
18
Internal dynamics
bit
24
Sampling frequency
kHz
44.1
PRESETS number 15
Effects
HALL REVERB, ROOM REVERB, PLATE
REVERB, STEREO DELAY
GENERAL SPECIFICATIONS
Frequency response 20Hz - 60kHz, ±1dB
Hum & Noise -90dB
THD <0.05% @ 1kHz
Crosstalk
FADER
MUTE
-85dB
-84dB
Maximum levels
MIC IN
TAPE IN
other outputs
MIX OUT (XLR)
other outputs
+14dBu
+16dBu
+22dBu
+28dBu
+22dBu
Power supply see label on the apparatus
Weight
kg
11
Dimensions
mm (WxHxD)
440x92x375
TAPE RCA phono
HEADPHONES output Stereo JACK
EQ
Balanced JACK
MIC input Balanced XLR-F
LINE input Balanced JACK
STEREO LINE input
EQ
