Lennox 13ACC-036 User Manual

Page 2
SPECIFICATIONS
Cooling
Model No. 13ACC−024 13ACC−030 13ACC−036 13ACC−037
Cooling
Data
Nominal Size − Tons (kW) 2 (7.0) 2.5 (8.8) 3 (10.6) 3 (10.6)
Connections
(t)
Liquid line o.d. − in. (mm) 3/8 (9.5) 3/8 (9.5) 3/8 (9.5) 3/8 (9.5)
(sweat)
Suction line o.d. − in. (mm) 3/4 (19.1) 3/4 (19.1) 7/8 (22.2) 7/8 (22.2)
Condenser
Cil
Net face area
ft (
2
)
Outer coil 15.21 (1.41) 15.21 (1.41) 15.21 (1.41) 19.83 (1.84)
Coil  sq. ft. (m
2
)
Inner coil 5.44 (0.51)
14.50 (1.35) 14.50 (1.35) 18.90 (1.76)
Tube diameter − in. (mm) & number of rows 5/16 (8) − 1.37 5/16 (8) − 2 5/16 (8) − 2 5/16 (8) − 2
Fins per inch (m) 22 (866) 22 (866) 22 (866) 22 (866)
sRefrigerant (HCFC22) furnished 5 lbs. 4 oz. (2.38
kg)
6 lbs. 13 oz. (3.09
kg)
7 lbs. 6 oz. (3.35
kg)
9 lbs. 3 oz. (4.17
kg)
Condenser
F
Diameter − in. (mm) & Number of blades 18 (457) − 3 18 (457) − 4 18 (457) − 4 18 (457) − 4
Fan
Motor output − hp (W) 1/6 (124) 1/6 (124) 1/6 (124) 1/6 (124)
Cfm (L/s) 2500 (1180) 2450 (1155) 2450 (1155) 2410 (1135)
Rpm 1100 1100 1100 1100
Watts 200 200 200 180
Shipping Data lbs. (kg) 1 package 155 (70) 175 (79) 180 (82) 191 (87)
Optional Accessories – MUST BE ORDERED EXTRA
Compressor Crankcase Heater 18K20 18K20 18K20 18K20
Compressor Monitor (Canada Only) 45F08 45F08 45F08 45F08
Hail Guard 17L73 17L73 17L73
ÉÉÉÉÉÉ
Low Ambient Kit (LB57113BC) 24H77 24H77 24H77 24H77
Plastic
Mti
Model Number − Catalog Number MB2S − 69J06 MB2S − 69J06 MB2S − 69J06 MB2S − 69J06
Mounting
Base
Dimensions − W x D x H − in. 22−1/4 x 22−1/4 x 3 22−1/4 x 22−1/4 x 3 22−1/4 x 22−1/4 x 3 22−1/4 x 22−1/4 x 3
Base
mm 565 x 565 x 76 565 x 565 x 76 565 x 565 x 76 565 x 565 x 76
Shipping Weight 6 lbs. (3 kg) 6 lbs. (3 kg) 6 lbs. (3 kg) 6 lbs. (3 kg)
Refrigerant
Li S t
20 ft. (6 m) length L15−41−20 L15−41−20 Not Available Not Available
g
Line Set
30 ft. (9.1 m) length L15−41−30 L15−41−30 L15−65−30 L15−65−30
40 ft. (12.2 m) length L15−41−40 L15−41−40 L15−65−40 L15−65−40
50 ft. (15.2 m) length L15−41−50 L15−41−50 L15−65−50 L15−65−50
Suction Line o.d. − in. (mm) 3/4 (19) 3/4 (19) 7/8 (22.2) 7/8 (22.2)
Liquid Line o.d. − in. (mm) 3/8 (9.5) 3/8 (9.5) 3/8 (9.5) 3/8 (9.5)
Timed−Off Control (LB−50709BK) 47J27 47J27 47J27 47J27
Unit StandOff Kit 94J45 94J45 94J45 94J45
*Refrigerant charge sufficient for 20 ft. (6.1 m) length of refrigerant lines.
Cooling
Model No. 13ACC−042 13ACC−047 13ACC−048 13ACC−060
Cooling
Data
Nominal Size − Tons (kW) 3.5 (12.3) 4 (14.1) 4 (14.1) 5 (17.6)
Connections
(t)
Liquid line o.d. − in. (mm) 3/8 (9.5) 3/8 (9.5) 3/8 (9.5) 3/8 (9.5)
(sweat)
Suction line o.d. − in. (mm) 7/8 (22.2) 11/8 (28.6) 7/8 (22.2) 11/8 (28.6)
Condenser
Cil
Net face area
ft (
2
)
Outer coil 15.21 (1.41) 24.5 (2.28) 21.11 (1.96) 21.11 (1.96)
Coil  sq. ft. (m
2
)
Inner coil 14.50 (1.35)
23.56 (2.19) 20.31 (1.89) 20.31 (1.89)
Tube diameter − in. (mm) & number of rows 5/16 (8) − 2 5/16 (8) − 2 5/16 (8) − 2 5/16 (8) − 2
Fins per inch (m) 22 (866) 22 (866) 22 (866) 22 (866)
sRefrigerant (HCFC22) furnished 7 lbs. 14 oz. (3.57 kg) 11 lbs. 1 oz. (5.02 kg) 10 lbs. 1 oz. (4.56 kg) 10 lbs. 11 oz. (4.85 kg)
Condenser
F
Diameter − in. (mm) & Number of blades 18 (457) − 4 22 (559) − 4 22 (559) − 4 22 (559) − 4
Fan
Motor output − hp (W) 1/3 (249) 1/4 (186) 1/3 (249) 1/3 (249)
Cfm (L/s) 2930 (1385) 3830 (1805) 3890 (1835) 3890 (1835)
Rpm 1100 825 1085 1085
Watts 310 330 375 375
Shipping Data lbs. (kg) 1 package 186 (84) 226 (103) 250 (113) 254 (115)
Optional Accessories – MUST BE ORDERED EXTRA
Compressor Crankcase Heater 18K20 18K20 18K20 18K20
Compressor Monitor (Canada Only) 45F08 45F08 45F08 45F08
Hail Guard 17L73
ÉÉÉÉÉÉ
17L74 17L74
Low Ambient Kit (LB57113BC) 24H77 24H77 24H77 24H77
Plastic
Mti
Model Number − Catalog Number MB2S − 69J06 MB2L − 69J07 MB2L − 69J07 MB2L − 69J07
Mounting
Base
Dimensions − W x D x H − in. 22−1/4 x 22−1/4 x 3 32 x 34 x 3 32 x 34 x 3 32 x 34 x 3
Base
mm 565 x 565 x 76 813 x 864 x 76 813 x 864 x 76 813 x 864 x 76
Shipping Weight 6 lbs. (3 kg) 15 lbs. (7 kg) 15 lbs. (7 kg) 15 lbs. (7 kg)
Refrigerant
Li S t
20 ft. (6 m) length Not Available Field Fabricate Not Available Field Fabricate
g
Line Set
30 ft. (9.1 m) length L15−65−30 Field Fabricate L15−65−30 Field Fabricate
40 ft. (12.2 m) length L15−65−40 Field Fabricate L15−65−40 Field Fabricate
50 ft. (15.2 m) length L15−65−50 Field Fabricate L15−65−50 Field Fabricate
Suction Line o.d. − in. (mm) 7/8 (22.2) 1−1/8 (28.5) 7/8 (22.2) 1−1/8 (28.5)
Liquid Line o.d. − in. (mm) 3/8 (9.5) 3/8 (9.5) 3/8 (9.5) 3/8 (9.5)
Timed−Off Control (LB−50709BK) 47J27 47J27 47J27 47J27
Unit StandOff Kit 94J45 94J45 94J45 94J45
*Refrigerant charge sufficient for 20 ft. (6.1 m) length of refrigerant lines.
