13ACX SERIES
Model Number
Unit Outdoor Fan
Sound Rating Number
(dB)
1
Factory Refrigerant
Charge
2
Number of Blades Diameter - inches.
13ACX-030-230-01 76 6 lbs. 3 oz. 4 18
13ACX-030-230-02 76 4 lbs. 4 oz. 4 18
13ACX-030-230-03 76 5 lbs. 13 oz. 4 18
13ACX-030-230-10 through -13, -15 76 4 lbs. 4 oz. 4 18
13ACX-030-230-17, -18, -19 76 5 lbs. 2 oz. 4 18
1
Tested according to AHRI Standard 270-2008 test conditions.
2
Refrigerant charge sufficient for 15 feet length of refrigerant lines.
Model Number
Unit Outdoor Fan
Sound Rating Number
(dB)
1
Factory Refrigerant
Charge
2
Number of Blades Diameter - inches.
13ACX-036-230-01 76 6 lbs. 7 oz. 4 18
13ACX-036-230-02 through -16 76 5 lbs. 9 oz. 4 18
13ACX-036-230-17, -18 76 5 lbs. 4 oz. 4 18
1
Tested according to AHRI Standard 270-2008 test conditions.
2
Refrigerant charge sufficient for 15 feet length of refrigerant lines.
Model Number
Unit Outdoor Fan
Sound Rating Number
(dB)
1
Factory Refrigerant
Charge
2
Number of Blades Diameter - inches.
13ACX-042-230-01 79 8 lbs. 3 oz. 4 22
13ACX-042-230-03 79 7 lbs. 6 oz. 4 22
13ACX-042-230-10 through -16 79 6 lbs. 6 oz. 4 22
13ACX-042-230-17, -18 79 6 lbs. 8 oz. 4 22
1
Tested according to AHRI Standard 270-2008 test conditions.
2
Refrigerant charge sufficient for 15 feet length of refrigerant lines.
Model Number
Unit Outdoor Fan
Sound Rating Number
(dB)
1
Factory Refrigerant
Charge
2
Number of Blades Diameter - inches.
13ACX-048-230-01 79 8 lbs. 4 oz. 4 22
13ACX-048-230-03 79 8 lbs. 12 oz. 4 22
13ACX-048-230-10 through -16 79 7 lbs. 8 oz. 4 22
13ACX-048-230-17, -18, -19 79 7 lbs. 12 oz. 4 22
1
Tested according to AHRI Standard 270-2008 test conditions.
2
Refrigerant charge sufficient for 15 feet length of refrigerant lines.
Model Number
Unit Outdoor Fan
Sound Rating Number
(dB)
1
Factory Refrigerant
Charge
2
Number of Blades Diameter - inches.
13ACX-060-230-01 79 11 lbs. 2 oz. 4 22
13ACX-060-230-02 79 10 lbs. 0 oz. 4 22
13ACX-060-230-05 79 11 lbs. 6 oz. 4 22
13ACX-060-230-10 through -16 79 10 lbs. 0 oz. 4 22
13ACX-060-230-17, -18 79 9 lbs. 0 oz. 4 22
1
Tested according to AHRI Standard 270-2008 test conditions.
2
Refrigerant charge sufficient for 15 feet length of refrigerant lines.

Lennox 14ACX Specifications

General

Compressor Type	Single-stage
Cooling Capacity (BTU/h)	18, 000 to 60, 000
Refrigerant	R-410A
Energy Star Certified	No
Voltage	208/230V
Phase	1
Unit Weight	Varies by model
Dimensions (H x W x D)	Varies by model
SEER Rating	14
Cooling Capacity	1.5 to 5 tons
Sound Level (dBA)	76
