14ACX SERIES
Table 5. HFC-410A Temperature — Pressure (Psig)
°F °C Psig °F °C Psig
-40 -40.0 11.6 60 15.6 170
-35 -37.2 14.9 65 18.3 185
-30 -34.4 18.5 70 21.1 201
-25 -31.7 22.5 75 23.9 217
-20 -28.9 26.9 80 26.7 235
-15 -26.1 31.7 85 29.4 254
-10 -23.3 36.8 90 32.2 274
-5 -20.6 42.5 95 35.0 295
0 -17.8 48.6 100 37.8 317
5 -15.0 55.2 105 40.6 340
10 -12.2 62.3 110 43.3 365
15 -9.4 70.0 115 46.1 391
20 -6.7 78.3 120 48.9 418
25 -3.9 87.3
125 51.7 446
30 -1.1 96.8 130 54.4 476
35 1.7 107 135 57.2 507
40 4.4 118 140 60.0 539
45 7.2 130
145 62.8 573
50 10.0 142
150 65.6 608
55 12.8 155
Table 6. Applicable Charging Sticker by Unit Model Number
Unit Model Number
Unit Charging Sticker Numbers
401216S 401289S 580053-01 580336-01 580438-01 580488-01 580754-01
Referenced charging stickers above are located at the end of this manual.
