PROBLEM 2: UNIT FAILS TO FIRE IN THE HEATING MODE, COMBUSTION AIR INDUCER DOES
NOT ENERGIZE (CONT.).
Condition Possible Cause Corrective Action/Comments
2.3
- Unit operates with a cooling and conĆ
tinuous fan demand.
- Combustion air inducer will not start
with a Heating demand.
- Diagnostic lights flash the pressure
switch failure code 2 5 minutes after
2.3.1
Miswiring of furnace or improper conĆ
nections to combustion air inducer.
ACTION 1 - Check for correct wiring and loose
connections. Correct wiring and/or replace any
loose connections.
switch failure code 2.5 minutes after
heating demand.
LED#1-Off,
LED#2-Slow Flash
2.3.2
Combustion air inducer failure.
ACTION 1 - If there is 120V to combustion air inĆ
ducer and it does not operate, replace combusĆ
tion air inducer.
PROBLEM 3: UNIT FAILS TO FIRE IN THE HEATING MODE, COMBUSTION AIR BLOWER
ENERGIZES, IGNITOR IS NOT ENERGIZED.
Condition Possible Cause Corrective Action/Comments
3.1
- Unit operates with a cooling and
continuous fan demand.
- Combustion air inducer energizes
with a heating demand
3.1.1
Pressure switch does not close due
to incorrect routing of the pressure
switch lines.
ACTION 1 - Check that the pressure switch lines
are correctly routed. Correctly route pressure
switch lines.
with a heating demand.
- Diagnostic lights flash the pressure
switch failure code 2.5 minutes after
heating demand.
3.1.2
Pressure switch does not close due
to obstructions in the pressure lines.
ACTION 1 - Remove any obstructions from the
the pressure lines and/or taps.
g
LED#1-Off
3.1.3
Pressure switch lines damaged
ACTION 1 - Check pressure switch lines for
leaks. Replace any broken lines.
LED#1 Off
LED#2-Slow Flash
3.1.4
Condensate in pressure switch line.
ACTION 1 - Check pressure switch lines for conĆ
densate. Remove condensate from lines. Check
that the condensate lines are located correctly.
3.1.5
Pressure switchdoes not close due to
a low differential pressure across the
pressure switch.
ACTION 1 - Check the differential pressure
across the pressure switch. This pressure
should exceed the set point listed on the
switch.
ACTION 2 - Check for restricted inlet vent. ReĆ
move all blockage.
ACTION 3 - Check for proper vent sizing and
run length. See installation instructions.
3.1.6
Wrong pressure switch installed in
the unit, or pressure switch is out of
calibration.
ACTION 1 - Check that the proper pressure
switch is installed in the unit. Replace pressure
switch if necessary.
3.1.7
Miswiring of furnace or improper conĆ
nections at pressure switch.
ACTION 1 - Check for correct wiring and loose
connections. Correct wiring and/or replace any
loose connections.
3.1.8
Pressure switch failure.
ACTION 1 - If all the above modes of failure have
been checked, the pressure switch may have
failed. Replace pressure switch and determine if
unit will operate.
