Page 16
Blower Data – Upow and Horizontal
CBX25UH-024 BLOWER PERFORMANCE
External Static
Pressure
Air Volume at Various Blower Speeds
High Medium Low
Pa in. w.g. L/s cfm L/s cfm L/s cfm
25 0.10 415 880 389 825 347 735
50 0.20 382 810 354 750 321 680
75 0.30 342 725 314 665 285 605
100 0.40 290 615 264 560 219 465
125 0.50 198 420 184 390 158 335
NOTE - All air data measured external to unit with dry coil and 25 mm (1 inch)
CBX25UH-030 BLOWER PERFORMANCE
External Static
Pressure
Air Volume at Various Blower Speeds
High Medium Low
Pa in. w.g. L/s cfm L/s cfm L/s cfm
25 0.10 524 1110 479 1015 406 860
50 0.20 484 1025 444 940 378 800
75 0.30 434 920 389 825 335 710
100 0.40 373 790 330 700 285 605
125 0.50 297 630 276 585 236 500
NOTE - All air data measured external to unit with dry coil and 25 mm (1 inch)
CBX25UH-036 BLOWER PERFORMANCE
External Static
Pressure
Air Volume at Various Blower Speeds
High Medium Low
Pa in. w.g. L/s cfm L/s cfm L/scfm
25 0.10 6751430 5971265 5171095
50 0.20 6321340 5621190486 1030
75 0.30 5851240 5211105451 955
1000.40533 1130 4721000 394835
1250.50448 950399 845342 725
NOTE - All air data measured external to unit with dry coil and 25 mm (1 inch)
CBX25UH-048 BLOWER PERFORMANCE
External Static
Pressure
Air Volume at Various Blower Speeds
High Medium Low
Pa in. w.g. L/s cfm L/s cfm L/scfm
25 0.10 9151940 8451790 7391565
50 0.20 8821870 8161730 7271540
75 0.30 8451790 7881670 7081500
1000.40805 1705 7551600 6841450
1250.50755 1600 7131510 6491375
NOTE - All air data measured external to unit with dry coil and 25 mm (1 inch)
CBX25UH-060 BLOWER PERFORMANCE
External Static
Pressure
Air Volume at Various Blower Speeds
High Medium Low
Pa in. w.g. L/s cfm L/scfm L/scfm
25 0.10 958 2030 8561815 7551600
50 0.20 932 1975 8311760 7271540
75 0.30 904 1915 8051705 7031490
100 0.40 878 1860 7791650 6801440
125 0.50 854 1810 7551600 6581395
NOTE - All air data measured external to unit with dry coil and 25 mm (1 inch)
