506294−01
TO INCREASE MOTOR
SPEED, DISCONNECT GRN
WIRE AND CONNECT YEL
WIRE.
MOTOR SPEED
TAPS 1 AND 2
Figure 10. Motor Speed Taps (208/230V, Single Phase)
MOTOR SPEED
TAPS 1 AND 2
TO INCREASE MOTOR
SPEED, DISCONNECT GRN
WIRE AND CONNECT YEL
WIRE.
Figure 11. Motor Speed Taps  460V, 3−Phase, 60Hz  Single Phase (−036, −048 and −060 only)
