Lennox CBX32MV-060

Page 14
CBX32MV
CBX32MV Horizontal Left- and Right-Hand Unit Dimensions — Inches (mm)
LIQUID
LINE
SUCTION
LINE
SUPPLY
AIR
OPENING
FILTER
LOW VOLTAGE
INLETS
(BOTTOM AND
RIGHT SIDE)
TOP VIEW
FRONT VIEW
BLOWER
H
B
C
D
LIQUID
LINE
SUCTION
LINE
CONDENSATE
DRAINS (2)
(UPFLOW AND
DOWNFLOW)
CONDENSATE
DRAINS (2)
(HORIZONTAL)
COIL
3/4 (19)
3/4 (19)
1‐1/2
(38)
1‐3/4
(44)
5‐3/4
(46)
2
(51)
1‐1/8
(29)
RETURN AIR
OPENING
F
E
5/8 (16)
5/8 (16)
5/8 (16)
END VIEW
AIR
FLOW
OPTIONAL ELECTRIC
HEAT (FIELD-INSTALLED)
11‐1/16
(281)
LINE VOLTAGE
INLETS (TOP
AND RIGHT
SIDE)
5‐3/8
(137)
4‐3/8
(111)
LIQUID
LINE
SUCTION
LINE
SUPPLY
AIR
OPENING
FILTER
LOW VOLTAGE
INLETS (TOP AND
LEFT SIDE)
END VIEW
BLOWER
B
C
D
COIL
3/4 (19)
3/4 (19)
3/4 (19)
RETURN
AIR OPENING
F
E
5/8 (16)
5/8 (16)
5/8 (16)
END VIEW
AIR
FLOW
OPTIONAL ELECTRIC
HEAT (FIELD INSTALLED)
LINE VOLTAGE INLETS
(BOTTOM AND LEFT SIDE)
Horizontal Position
(Right‐Hand Air
Discharge)
FILTER ACCESS
FILTER ACCESS
5‐3/4
(146)
1‐1/2 (38)
1‐3/4
(44)
CONDENSATE DRAINS (2)
(HORIZONTAL)
A
5/8 (16)
G
H
A
5/8 (16)
G
1 (25)
1 (25)
11‐1/16
(281)
PIPING PLATE
DETAIL
LIQUID
LINE
SUCTION LINE
2
(51)
1‐1/8
(29)
5‐3/8
(137)
4‐3/8
(111)
PIPING PLATE
DETAIL
Horizontal Position
(Left‐Hand Air
Discharge)
TOP VIEW
FRONT VIEW
3/4 (19)
END VIEW
FOR DIMENSIONS “A”
THROUGH “H”, SEE CHART ON
PAGE 13.
