EVAPORATOR PUMP(S) CONTROL
Function
Ensure the presence of a flow rate of heat transfer fluid in the evaporator heat exchanger.
Description
Seven types of control rules can be set. They are defined using the menu 3112 on the DS50 Service
Display.
• If 3112 = Started .........................CLIMATIC
TM
50 does not control the pumps
• If 3112 = Stopped, ......................Pumps are stopped.
• If 3112 = P1 Only .........................CLIMATIC
TM
50 Control only runs pump n°1.
• If 3112 = P2 Only ........................CLIMATIC
TM
50 Control only runs pump n°2.
• If 3112 P1N P2R..........................CLIMATIC
TM
50 Control handles both pumps with
N°1 as standard and N° 2 as backup.
• If 3112 = P2N P1R ......................CLIMATIC
TM
50 Control handles both pumps with
N°2 as standard and N° 1 as backup.
• If 3112 – Clock.............................CLIMATIC™ 50 controls handles both pumps equalizing running
times and switching from one pump to the other every Tuesday at
02h00 am.
This
Pump N°1 is running if all of the following conditions are met:
" At least one ON/OFF of circuit “n” is ON
" Unit remote ON/OFF is ON *
" NOT in the unoccupied zone*
" Set point 3112 is not set to “Stopped”
" Configuration 3841 is not set to “No”
" Pump has been stopped for 1 minute or is already running.
" There is no electrical fault on the pump
" There is to « flow rate » fault
* These conditions are ignored if the outdoor temperature is below set point 3341 + 1°C and if the outlet
water temperature is below set point +1°C, in order to prevent the water from freezing.
A pump can be controlled by the CLIMATIC
TM
50 even if electrically the network pump is not handled by the
refrigeration unit.
In the case where the customer is handling the control of his own pump, the following procedure must be
followed:
# Start the pump at least 1 minute before validating the remote ON/OFF switch operation.
# Switch off the pump 2 minutes at least after the remote ON/OFF switch has gone to 0.
