DS50 MENU TREE – ECOLOGIC/ECOMAX RANGE

Main screen Code Description Code Description Code Description Code Unit

1-Alarm 1000 1-(date).(time)

2-(date).(time)

3-(date).(time)

2-Data 2000 1-General 2100 1-Temperature 2110 1-Outside 2111 °C

2-Inlet 2112 °C

3-Outlet 2113 °C

4-Offset 2114 °C

5-Wat/Cond 2115 °C

2-Circuit 1 2120 1-SuperHeat 2121 °C

2-T°. Condensing 2122 °C

3-T°- Saturated 2123 °C

4-T°. Suction 2124 °C

5-P. Condensing 2125 b

6-P. Saturated 2126 b

7-T° Discharge 1 2127 °C

8- T° Discharge 2 2128 °C

3-Circuit 2 2130 1-SuperHeat 2131 °C

2- T°.Condensing 2132 °C

3- T°- Saturated. 2133 °C

4- T°. Suction. 2134 °C

5- P. Condensing 2135 b

6- P. Saturated 2136 b

7-T° Discharge 1 2137 °C

8- T° Discharge 2 2138 °C

4-Circuit 3 2140 1-SuperHeat 2141 °C

2-T°. Condensing 2142 °C

3-T°- Saturated 2143 °C

4-T°. Suction 2144 °C

5-P. Condensing 2145 b

6-P. Saturated 2146 b

5-Circuit 4 2150 1-SuperHeat 2151 °C

2- T°.Condensing 2152 °C

3- T°- Saturated. 2153 °C
