Main screen Code Description Code Description Code Description Code Unit
3-Position 2513 ~
2-Circuit 2 2520 1-Config. 2521 Liste : No / Yes
2-State 2522 Liste : Stopped / Started / Wait.Flow / Wait.CH / Schedule / Switch / Fault(1)
3-Position 2523 ~
3-Circuit 3 2530 1-Config. 2531 Liste : No / Yes
2-State 2532 Liste : Stopped / Started / Wait.Flow / Wait.CH / Schedule / Switch / Fault(1)
3-Position 2533 ~
4-Circuit 4 2540 1-Config. 2541 Liste : No / Yes
2-State 2542 Liste : Stopped / Started / Wait.Flow / Wait.CH / Schedule / Switch / Fault(1)
3-Position 2543 ~
6-Ventilation 2600 1-Fan - Circuit 1 2610 1-Config. 2611
Liste : No / 1.Yes / 2.Yes / 3.Yes / 4.Yes / 5.Yes / 1.Modulat. / 2.Modulat. / 3.Modulat. /
4.Modulat. / 5.Modulat. / 1.LowSpeed / 2.LowSpeed / 3.LowSpeed / 4.LowSpeed /
5.LowSpeed
2-State 2612
Liste : Stopped / Start.0.5 / Started1 / Start.1.5 / Started2 / Start.2.5 / Started3 / Start.3.5 /
Started4 / Start.4.5 / Started5 / Wait.Flow / Wait.CH / Fault(1)
3-Sw State 2613 On/Off
4-Relay 1 2614 On/Off
5-Relay 2. 2615 On/Off
6-Relay 3 2616 On/Off
7-Relay 4 2617 On/Off
8-Relay 5 2618 On/Off
9-Modulat. 2619 %
1-Fan - Circuit 2 2620 1-Config. 2621
Liste : No / 1.Yes / 2.Yes / 3.Yes / 4.Yes / 5.Yes / 1.Modulat. / 2.Modulat. / 3.Modulat. /
4.Modulat. / 5.Modulat. / 1.LowSpeed / 2.LowSpeed / 3.LowSpeed / 4.LowSpeed /
5.LowSpeed
2-State 2622
Liste : Stopped / Start.0.5 / Started1 / Start.1.5 / Started2 / Start.2.5 / Started3 / Start.3.5 /
Started4 / Start.4.5 / Started5 / Wait.Flow / Wait.CH / Fault(1)
3-Sw State 2623 On/Off
4-Relay 1 2624 On/Off
5-Relay 2. 2625 On/Off
6-Relay 3 2626 On/Off
7-Relay 4 2627 On/Off
8-Relay 5 2628 On/Off
9-Modulat. 2629 %
2-Fan 2 - Circuit 3 2630 1-Config. 2631
Liste : No / 1.Yes / 2.Yes / 3.Yes / 4.Yes / 5.Yes / 1.Modulat. / 2.Modulat. / 3.Modulat. /
4.Modulat. / 5.Modulat. / 1.LowSpeed / 2.LowSpeed / 3.LowSpeed / 4.LowSpeed /
5.LowSpeed
2-State 2632
Liste : Stopped / Start.0.5 / Started1 / Start.1.5 / Started2 / Start.2.5 / Started3 / Start.3.5 /
Started4 / Start.4.5 / Started5 / Wait.Flow / Wait.CH / Fault(1)
3-Sw State 2633 On/Off
