0906-E
81
bit.5 = Pump, 1
bit.6 = Pump, 2
bit.7 = Real Time Clock
bit.8 = BE50
bit.9 = BM50, Slave
bit.10 = Probes & Sensors
bit.11 = Condenser
bit.12 = Fans, Condenser, Circuit 1
bit.13 = Fans, Condenser, Circuit 2
bit.14 = Fans, Condenser, Circuit 3
bit.15 = Fans, Condenser, Circuit 4
20H 32
R/W
[Alarm]
bit.0 = Compressor, Circuit 1, Electric Protection
bit.1 = Compressor, Circuit 1, High Pressure
bit.2 = Compressor, Circuit 1, Low Pressure or Freeze protection
bit.3 = Compressor, Circuit 2, Electric Protection
bit.4 = Compressor, Circuit 2, High Pressure
bit.5 = Compressor, Circuit 2, Low Pressure or Freeze protection
bit.6 = Compressor, Circuit 3, Electric Protection
bit.7 = Compressor, Circuit 3, High Pressure
bit.8 = Compressor, Circuit 3, Low Pressure or Freeze protection
bit.9 = Compressor, Circuit 4, Electric Protection
bit.10 = Compressor, Circuit 4, High Pressure
bit.11 = Compressor, Circuit 4, Low Pressure or Freeze protection
bit.12 = Compressor, Circuit 1, Electronic Expansion Valve
bit.13 = Compressor, Circuit 2, Electronic Expansion Valve
bit.14 = Compressor, Circuit 3, Electronic Expansion Valve
bit.15 =Compressor, Circuit 4, Electronic Expansion Valve
√ √ …
21H 33
R 1 = 1
[Alarm] Code Error √ √ 1000
22H 34
R 10 = 1.0°c
[Temperature] Intlet, Water √ √ 2112
23H 35
R 10 = 1.0°c
[Temperature] Outdoor, Air √ √ 2111
24H 36
R 10 = 1.0°c
[Temperature] Outlet, Water √ √ 2113
25H 37
R 10 = 1.0b
[Pressure] High, Circuit 1 √ √ 2125
26H 38
R 10 = 1.0b
[Pressure] Low, Circuit 1 √ √ 2126
27H 39
R 10 = 1.0b
[Pressure] High, Circuit 2 √ √ 2135
28H 40
R 10 = 1.0b
[Pressure] Low, Circuit 2 √ √ 2136
29H 41
R 10 = 1.0b
[Pressure] High, Circuit 3 √ 2145
2AH 42
R 10 = 1.0b
[Pressure] Low, Circuit 3 √ 2146
2BH 43
R 10 = 1.0b
[Pressure] High, Circuit 4 √ 2155
2CH 44
R 10 = 1.0b
[Pressure] Low, Circuit 4 √ 2156
2DH 45
R 1 = 1%
[% of opening] Fan, Modulation, Circuit 1 √ √ 2619
2EH 46
R 1 = 1%
[% of opening] Fan, Modulation, Circuit 2 √ √ 2629
2FH 47
R 1 = 1%
[% of opening] Fan, Modulation, Circuit 3 √ 2639
30H 48
R 1 = 1%
[% of opening] Fan, Modulation, Circuit 4 √ 2649
31H 49
R 10 = 1.0°c
[Dry contact] Temperature, Free 1, BE50-J9-B1 √ √ 2191
32H 50
R 10 = 1.0°c
[Dry contact] Temperature, Free 2, BE50-J9-B2 √ √ 2192
33H 51
R 10 = 1.0°c
[Dry contact] Temperature, Free 3, BE50-J10-B3 √ √ 2193
34H 52
R 10 = 1.0°c
[Dry contact] Temperature, Free 4, BE50-J10-B4 √ √ 2194
35H 53
R 1 = 1
[Fan] Numbers which run, Circuit 1 √ √ …
36H 54
R 1 = 1
[Fan] Numbers which run, Circuit 2 √ √ …
