bit.8 = Compressor, Circuit 3, Low
Pressure or Freeze protection
bit.9 = Compressor, Circuit 4, Electric
Protection
bit.10 = Compressor, Circuit 4, High
Pressure
bit.11 = Compressor, Circuit 4, Low
Pressure or Freeze protection
bit.12 = Compressor, Circuit 1,
Electronic Expansion Valve
bit.13 = Compressor, Circuit 2,
Electronic Expansion Valve
bit.14 = Compressor, Circuit 3,
Electronic Expansion Valve
bit.15 =Compressor, Circuit 4,
Electronic Expansion Valve
Type Index Name NV Type NV Direction Index WA LC DS50
DGT 1 I_Sp_On_Unit 95 input 415
DGT 1 O_Sp_On_Unit 95 output 415
[On / Off] Unit
√ √ 3111
DGT 2 I_Sp_Reset 95 input 416
DGT 2 O_Sp_Reset 95 output 416
[Reset] Discharges the safety
measures of the unit
√ √ 3112
DGT 3 I_Sp_Unoc 95 input 417
DGT 3 O_Sp_Unoc 95 output 417
[BMS] Activation of the Inoccupation
mode [Off] occupation mode - [On]
inoccupation mode
√ √ 3935
DGT 17 O_Od_Alarm 95 output 431
[Alarm] General
√ √ 1000
DGT 18 O_Od_Pump_1 95 output 432
[On/Off] Pump, 1
√ √ 2315
DGT 19 O_Od_Pump_2 95 output 433
[On/Off] Pump, 2
√ √ 2317
DGT 20 O_Od_Comp_11 95 output 434
[On/Off] Compressor 1, Circuit 1
√ √ 2416
DGT 21 O_Od_Comp_21 95 output 435
[On/Off] Compressor 2, Circuit 1
√ √ 2426
DGT 22 O_Od_Comp_31_3 95 output 436
[On/Off] Compressor 3, Circuit 1 (WA)
or Compressor 1, Circuit 3 (LC)
√ √ 2456
DGT 23 O_Od_CompHPump_1 95 output 437
[On/Off] Compressor, Heat pump,
Circuit 1
√ 2417
DGT 24 O_Od_Comp_12 95 output 438
[On/Off] Compressor 1, Circuit 2
√ √ 2436
DGT 25 O_Od_Comp_22 95 output 439
[On/Off] Compressor 2, Circuit 2
√ √ 2446
DGT 26 O_Od_Comp_32_4 95 output 440
[On/Off] Compressor 3, Circuit 2 (WA)
or Compressor 1, Circuit 4 (LC)
√ √ 2466
DGT 27 O_Od_CompHPump_2 95 output 441
[On/Off] Compressor, Heat pump,
Circuit 2
√ 2447
DGT 28 O_Od_FCoil_1 95 output 442
[On/Off] Fans, Circuit 1
√ √ 2614
DGT 29 O_Od_FCoil_2 95 output 443
[On/Off] Fans, Circuit 2
√ √ 2624
DGT 30 O_Od_FCoil_3 95 output 444
[On/Off] Fans, Circuit 3
√ 2634
DGT 31 O_Od_FCoil_4 95 output 445
[On/Off] Fans, Circuit 4
√ 2644
