9
Select Modes
1. HEAT/COOL allows the thermostat to switch
between heating and cooling automatically.
2. HEAT ONLY allows only heating demand.
3. COOL ONLY allows only cooling demand.
4. OFF indicates system has been turned off.
5. EMERGENCY HEAT allows heat pump
system to use a secondary heat source to
come on and reach the desired user
temperature setting faster.
6. SCHEDULES (1, 2 or 3) See Edit Schedules
on page 13 for customizing schedules).
7. ON, AUTO and CIRCULATE - Select by
touching the desired fan operation ON,
AUTO and CIRCULATE. When selected a
green check mark will be indicated.
If FAN mode AUTO, ON or CIRCULATE is
selected during scheduling for the current period,
the thermostat will indicate the current fan mode in
the information display (FAN ON or FAN CIRC).
In the CIRCULATE mode, the fan will follow the
setting configured under menu > settings > fan
>select fan mode. Under circulate the circulate
off time can be set from 1 to 30 minutes.
Fan Operation
The desired fan mode is selected in addition to
selected mode of operation.
Table 2. Fan Operation
on
Fan is NOT following
the schedule and runs
continuously until it is
changed from the seî
lect mode.
auto
Fan will follow the fan
setting in the selected
schedule.
circulate
Fan is following
schedule and cycles
during periods of
equipment inactivity.
Circulate off time is
set by the user.
