Page 11
ComfortSenset Touch Screen Thermostat
Options TabInstaller Settings (continued)
SMOOTH SET BACK(SSR) default is OFF. When en-
abled, smooth set back begins recovery up to 2 hours be-
fore the programmed time so that the programmed tem-
perature is reached at the corresponding programmed
event time. Assume 12°F per hour for first stage gas/elec-
tric heating and 6°F per hour for first stage compressor
based heating or cooling. With Smooth Set Back disabled,
the control will start a recovery at the programmed time.
Scroll to SMOOTH SET BACK; press ENTER. Use arrows
to select between ON or OFF. Press SAVE.
SMOOTH SET BACK
DEFAULT(OFF) ON
NOTE − Smooth Set Back and STG2 Lock Out operations
vary depending on equipment (see table 2).
SSR STG2 LOCK OUT[not available if SMOOTH SET
BACK is OFF] default is 20 minutes. Scroll to SSR STG2
LOCK OUT; press ENTER. Use arrows to select OFF or
the number of minutes before the programmed event time
that stage 2 is allowed to operate (OFF or 20 to 120 min-
utes in 10 minute increments). Press SAVE.
SSR STG2 LOCK OUT
DEFAULT(2OMIN) 4OMIN
Table 2. Smooth Set back Recovery (SSR) & SSR Stg 2 Lock Out Operation
Equipment
Available
SSR = Enabled;
SSR Stg 2 lock out = enabled
SSR = Enabled;
SSR Stg 2 lock−out = disabled (off)
1 stage HP with 1 or
2 stages elec backup
Run HP (Y1) only; all backup heat
(W1/W2) enabled 20 − 120 min before
wake up setpoint
Run HP (Y1) and have available backup heat (W1/W2) as needed.
2 stage HP with 1 or
2 stages elec backup
Run HP (Y1/Y2) only; all backup heat
(W1/W2) enabled 20 − 120 min before
wake up setpoint
Run HP (Y1/Y2) and have available backup heat (W1/W2) as
needed.
1 stage HP with 1
stage gas/oil backup
Run HP (Y1) only; all backup heat
(W1) enabled 20 − 120 min before
wake up setpoint
Run HP (Y1) until a 2nd stage demand is needed (by time/temp.
differential); then HP operation must stop and changeover and lock
in to W1 heat until setpoint reached.
1 stage HP with 2
stages gas/oil backup
or modulation furnace
Run HP (Y1) only; all backup heat
(W1/W2) enabled 20 − 120 min before
wake up setpoint
Run HP (Y1) until a 2nd stage demand is needed (by time/temp
differential); then HP operation must stop and changeover to
W1/W2 heat as needed; lock in W1/W2heat until setpoint reached.
2 stage HP with 1
stage gas/oil backup
Run HP (Y1/Y2) only; all backup heat
(W1/W2) enabled 20 − 120 min before
wake up setpoint
Run HP (Y1/Y2) until a 2nd stage demand is needed (by time/
temp. differential); then HP operation must stop & changeover and
lock in to W1 heat until setpoint reached
2 stage HP with 2
stages gas/oil backup
or modulation furnace
Run HP (Y1/Y2), all backup heat
(W1/W2) enabled 20 − 120 min before
wake up setpoint
Run HP (Y1/Y2) until a 2nd stage demand is needed (by time/
temp. differential); then HP operation must stop & changeover and
lock in to W1/W2 heat until setpoint reached.
2 stages gas/oil heat
or modulation furnace
Run W1 only; W2 enabled 20 − 120
min before wake up setpoint
Run W1 heat and bring on W2 heat until setpoint reached.
1 stage cooling Run Y1 to wake up set point Run Y1 heat until setpoint reached.
2 stage cooling Run Y1 during recovery enable Y2
field wake up set point
Run Y1 & Y2 heat as needed until setpoint reached.
