Lennox ComfortSense 7000

ComfortSenseE 7000 Touchscreen Thermostat / Page 5
FEATURES
Installer Settings
SYSTEM SETUP
− NON HEAT PUMP (default)
− Gas / Oil (Default)
− Electric
− No Heat
− HEAT PUMP
− Dual Fuel (Gas / Oil)
− Electric
− No Backup Heat
− COMPRESSOR STAGES (1 default or 2)
− INDOOR HEAT STAGES (1 default or 2 Stages)
OUTDOOR SENSOR
− YES or NO (default)
RESIDUAL COOL
− 0 (default), 30, 60, 90, 120 seconds
LOW BALANCE POINT
(Multi−stage Heat Pump)
− 25°F (default), adjustable (–40°F to high balance point)
HIGH BALANCE POINT
(Multi−stage Heat Pump)
− 50°F (default), adjustable (Low balance point to 75°F)
DEADBAND
− 4°F (default), adjustable (3 to 8°F)
SMOOTH SETBACK RECOVERY
− On (default) or Off
SMOOTH SETBACK RECOVERY STAGE 2 LOCKOUT
− 20 min. (default), adjustable (20 to 120 minutes)
CONTACT INFORMATION
− 2 lines of up to 19 alphanumeric characters
TEMPERATURE OFFSET
− 0°F (default), adjustable (–5 to 5°F). Offset displayed
temperature ± 5°F.
HUMIDITY OFFSET
− 0% (default), adjustable (–10 to 10%)
STG DELAY TIMERS
− On (default) or Off
COMPRESSOR PROTECT
− On (default) or Off
DAYLIGHT SAVINGS
− On (default) or Off
HUMIDITY SETTING
− HUMIDIFY
− Off (default), Dewpoint, Precision, Basic, adjustable
(15 to 45%) 45% default setting
− DEHUMIDIFY
− Off (default), Humiditrol, Precision, Basic, adjustable
(45 to 60%) 50% default setting
NOTE −Dewpoint and Humiditrol settings are only available with
optional remote Outdoor Temperature Sensor
.
STG 1 DIFF
− 1.0°F (default), adjustable (0.5 to 8.0°F)
STG 2 DIFF
− 0.5°F (default), adjustable (0.5 to 8.0°F)
STG 2 DELAY
− 20 min. (default), adjustable (5 to 120 minutes)
STG 3 DIFF
− 0.5°F (default), adjustable (0.5 to 8.0°F)
STG 3 DELAY
− 20 min. (default), adjustable (5 to 120 minutes)
STG 4 DIFF
− 0.5°F (default), adjustable (0.5 to 8.0°F)
STG 4 DELAY
− 20 min. (default), adjustable (5 to 120 minutes)
H/C STGS LOCKED IN
− YES or NO (default) turns heating stages off separately
STG 2 HP LOCK TEMP
− OFF (default) for dual fuel (lock out 2nd stage
compressor) applications, adjustable (–45 to 75°F)
CUSTOM REMINDER1
CUSTOM REMINDER2
User defined reminders can be a custom text message
(up to 19 alphanumeric characters)
RESET TO FACTORY
− Restores thermostat to original factory settings
NOTE − A hard" reset option is also available. See Programming
and Application Guide
.
ENERGY STAR DEFAULT
− Sets thermostat to conform to EPA ENERGY STAR
®
recommended setpoints.
WAKE − 6 AM, 70°F Heat, 78°F Cool
LEAVE − 8 AM, 62°F Heat, 85°F Cool
RETURN − 5 PM, 70°F Heat, 78°F Cool
SLEEP − 10 PM, 62°F Heat, 82°F Cool
SYSTEM TEST MODES
Installer run tests to check all cooling, heating, emergency
heating and fan outputs. Tests confirm signals between
thermostat and unit are being sent and received.
− TEST OUTPUTS
− OFF
− Y1 ON
− Y2 ON
− Y2 OFF
− W1 ON
− W1 OFF
− W2 ON
− W2 OFF
− FAN (G) ON
− FAN (G) OFF
− H ON
− H OFF
− D ON
− D OFF
− O ON (B OFF)
− B ON (O FF)
