11
SELECT MODE
1. HEAT/COOL allows the thermostat to switch
between heating and cooling automatically.
2. HEAT ONLY allows only heating demand.
3. COOL ONLY allows only cooling demand.
4. OFF indicates system has been turned off
5. EMERGENCY HEAT allows heat pump sys
tem to use a secondary heat source to come
on and reach the desired user temperature
setting faster.
6. SCHEDULES (up to two schedules and
holiday) (see Edit Schedules on page 16 for
customizing schedules).
7. ON, AUTO and CIRCULATE - Select by
touching the desired fan operation ON, AU
TO and CIRCULATE. A green check mark in
dicates the selected setting.
FAN OPERATION
If a particular FAN mode (AUTO, ON or CIRCU
LATE) was selected during scheduling for the cur
rent period, the thermostat will indicate the fan
mode in the information display.
In the CIRCULATE mode, the user can cycle the
fan for a programmed period of operation each
hour during periods when the heating or cooling
equipment is not running.
Table 2. Fan Operation
on
Fan is NOT following
the schedule and runs
continuously until it is
changed from the se
lect mode.
auto
Fan follows the fan set
ting in the selected
schedule.
circulate
Fan follows schedule
and cycles during
periods of equipment
inactivity.
Circulate off time is
dependent on user
settings.
