CONTROLS (continued)
Optional Accessories
iComfort
®
S30 Thermostat (part of the iComfort
®
Residential Communicating Control System)
The iComfort
®
S30 Thermostat recognizes and connects
to all iComfort
®
-enabled products to automatically
congure and control
the heating/cooling
system (based on
user-specied settings)
for the highest level of
comfort, performance
and efciency. Also
recognizes model
and serial number
information for iComfort
®
-enabled products to simplify
system setup.
Wi-Fi remote temperature monitoring and adjustment
through a home wireless network for desktop PCs,
laptops and apps for smartphones or tablets. Also
displays service alerts and reminders.
Dealer Dashboard features online real-time monitoring
of installed iComfort
®
systems.
A simple easy-to-use touchscreen allows complete
system conguration. Scheduled maintenance alerts,
system warnings and troubleshooting are also displayed
on thermostat screen.
Easy to read 7 in. high denition color display
(measured diagonally).
Conventional outdoor units (not iComfort
®
-enabled) can
easily be added and controlled by the iComfort
®
S30
Thermostat.
Installer setup screens allow quick and simple system
conguration without a manual, Installer can also run
tests on complete system or individual components for
easy maintenance and troubleshooting.
Serial communications bus (RSBus), with less wiring
than a conventional heating/cooling system, allows
system communication. Uses 4-wire, 18-gauge
standard thermostat wiring.
High Denition Color Display, Mag-Mount, Smart Hub
Controller, wallplate (for retrot installations) furnished
for easy installation.
See the iComfort
®
S30 Thermostat Product
Specications bulletin in the Controls section for more
information.
iComfort Wi-Fi
®
Thermostat (part of the iComfort
®
Residential Communicating Control System)
The iComfort Wi-Fi
®
Thermostat recognizes and
connects to all iComfort
®
-enabled products to
automatically
congure and control
the heating/cooling
system (based
on user-specied
settings) for the
highest level of
comfort, performance
and efciency. Also
recognizes model and serial number information for
iComfort
®
-enabled products to simplify system setup.
Wi-Fi remote temperature monitoring and adjustment
through a home wireless network for desktop PCs,
laptops and apps for smartphones or tablets. Also
displays service alerts and reminders.
Dealer Dashboard features online real-time monitoring
of installed iComfort
®
systems.
A simple easy-to-use touchscreen allows complete
system conguration. Scheduled maintenance alerts,
system warnings and troubleshooting are also displayed
on thermostat screen.
Easy to read 7-inch color screen (measured diagonally).
Conventional outdoor units (not iComfort
®
-enabled) can
easily be added and controlled by the iComfort Wi-Fi
®
Thermostat.
Installer setup screens allow quick and simple system
conguration without a manual, Installer can also run
tests on complete system or individual components for
easy maintenance and troubleshooting.
Serial communications bus (RSBus), with less wiring
than a conventional heating/cooling system, allows
system communication. Uses 4-wire, 18-gauge
standard thermostat wiring.
See the iComfort Wi-Fi
®
Thermostat Product
Specications bulletin in the Controls section for more
information.
Remote Outdoor Temperature Sensor
Used with the iComfort
®
-enabled thermostats.
When installed outdoors, sensor
allows thermostat to display outdoor
temperature. Sensor is auto-detected
when connected to thermostat.
NOTE - Sensor is required for
Humiditrol
®
applications.
NOTE - The outdoor sensor is
furnished as standard with iComfort
®
-enabled outdoor
units, optional for conventional units.
FEATURES
5 of 44 B17-0056
01/19/2017
