SPECIFICATIONS
General Data Model Number CBX32MV-018/024 CBX32MV-024/030 CBX32MV-036
Nominal tonnage 1.5 to 2 2 to 2.5 3
Refrigerant R-410A R-410A R-410A
Connections
in.
Suction / vapor (o.d.) line - sweat 5/8 3/4 3/4
Liquid line (o.d.) - sweat 3/8 3/8 3/8
Condensate drain - in. (fpt) (2) 3/4 (2) 3/4 (2) 3/4
Indoor
Coil
Net face area - ft.
2
3.56 4.44 5.0
Tube outside diameter - in. 3/8 3/8 3/8
Number of rows 3 3 3
Fins per inch 12 12 12
Blower Data Wheel nominal diameter x width - in. 10 x 7 10 x 8 10 x 8
Motor output - hp 1/2 1/2 1/2
Filters
1
Number and size - in. (1) 15 x 20 x 1 (1) 20 x 20 x 1 (1) 20 x 20 x 1
Shipping Data - 1 Package - lbs. 126 152 183
ELECTRICAL DATA
Voltage - phase - 60hz 208/230V-1ph 208/230V-1ph 208/230V-1ph
2
Maximum overcurrent protection (unit only) 15 15 15
3
Minimum circuit ampacity (unit only) 5 5 5
CONTROLS
iComfort
®
S30 Thermostat 12U67 12U67 12U67
iComfort Wi-Fi
®
Thermostat 10F81 10F81 10F81
ComfortSense
®
7500 Thermostat 13H14 13H14 13H14
4
Remote Outdoor Sensor (for dual fuel and Humiditrol
®
) X2658 X2658 X2658
5
Discharge Temperature Sensor 88K38 88K38 88K38
OPTIONAL ACCESSORIES - ORDER SEPARATELY
Circuit Breaker Cover Kit 82W01 82W01 82W01
Downow Combustible Flooring Base 34J72 44K15 44K15
Electric Heat See Electric Heat Data tables
Healthy Climate
Germicidal Light
UVC-24V (24V) X9423 X9423 X9423
Shielding Bafe (required) Y5172 Y5172
Y5172
UVC-41W-S (110/230v-1 ph) X9424 X9424 X9424
Shielding Bafe (required) Y5171 Y5171 Y5171
Horizontal Support Frame Kit 56J18 56J18 56J18
Hot Water Heat Kit 90W84 90W84 90W84
Side Return Unit Stand (Upow) 45K31 45K32 45K32
Single-Point Power Source Control Box 21H39 21H39 21H39
Wall Hanging Bracket Kit (Upow) 45K30 45K30 45K30
1
Disposable frame type lter.
2
HACR type circuit breaker or fuse.
3
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements. Use wires suitable for at least 167°F.
4
Remote Outdoor Temperature Sensor is used with conventional (non-iComfort
®
-enabled) outdoor units (sensor is furnished with iComfort
®
-enabled outdoor units).
Allows the thermostat to display outdoor temperature. Required in dual-fuel and Humiditrol
®
applications.
5
Optional for EvenHeater
®
electric heat operation and service diagnostics.
INSTALLATION CLEARANCES WITH ELECTRIC HEAT
Cabinet 0 inch (0 mm)
To Plenum 1 inch (25 mm)
To Outlet Duct within 3 feet (914 mm) 1 inch (25 mm)
Floor See Note #1
Service / Maintenance See Note #2
1
Units installed on combustible oors in the downow position with electric heat require optional downow combustible
ooring base.
2
Front service access - 24 inches (610 mm) minimum.
NOTE - If cabinet depth is more than 24 inches (610 mm), allow a minimum of the cabinet depth plus 2 inches (51 mm).
8 of 44 B17-0056
01/19/2017

Lennox DAVE LENNOX SIGNATURE CBX32MV Specifications

General

Type	Variable Speed Air Handler
Refrigerant	R-410A
Airflow	Up to 2000 CFM
Warranty	10-Year Limited Warranty
Nominal Cooling Capacity	1.5 - 5 Ton
Nominal Heating Capacity	Match with heat pump or furnace
Blower Motor	Variable Speed ECM
Filter	MERV 16
