Electric Heat Wiring Diagram Cross Reference
The following table provides a cross-reference for diagrams for specic electric heat models.
TABLE 1
Electric Heat Section Model Wiring Diagram #
ECB29-2.5-P 537764-01
ECB29-4-P 537764-01
ECB29-4CB-P 537764-01
ECB29-5-P 537764-01
ECB29-6-P 537764-01
ECB29-8-P 537816-01
ECB29-10-P 537770-02
ECB29-5CB-P 537764-01
ECB29-6CB-P 537764-01
ECB29-8CB-P 537816-01
ECB29-9CB-P 537770-02
ECB29-10CB-P 537770-02
ECB29-12.5CB-P 537787-02
ECB29-15CB-P 537787-02
ECB29-20CB-P 537760-02
ECB29-25CB-P 537786-01
ECB29-30CB-P 537786-01
ECB29-8-Y 537772-01
ECB29-10-Y 537772-01
ECB29-15CB-Y 537771-01
ECB29-20CB-Y 537788-01
ECB29-25CB-Y 537788-01
ECB29-10-G 531708W
ECB29-15-G 531708W
ECB29-20-G 531708W
ECB29-25-G 531708W
ECB29-20-J 531708W
ECB29-25-J 531708W
