Page 63
FIGURE 35. Checking Crankcase Heater Thermostat
STATUS CODE:
None
ERROR CODES:
None
Compressor Sound Cover
All units come with a soft-sided polyethylene molded outer shell compressor sound cover. The cover helps reduce any
unwanted operating sounds from the compressor. The cover features a hook/loop closure system for ease of installation
on the compressor.
FIGURE 36. Compressor Sound Cover
Suction Line Filter Drier (Rotary Compressor Models Only)
The EL23XCV-024, -036, -048 have a rotary compressor and have a factory installed suction line lter drier installed in
the suction line. Liquid drier is not required, but may be eld installed. The lter drier is designed to remove moisture and
foreign matter, which can lead to compressor failure.
FIGURE 37. Suction line lter drier
