Lennox EL23XCV Series

Page 59
IMPORTANT: If compressor replacement is required, remove the compressor through the top of the unit. Removal through
the access panel is not possible.
ELECTRICAL
CONNECTION
PLUG
LOCATION
(NOT
SHOWN)
DISCHARGE
SUCTION
EQUALIZATION
VALVE
EL23XCV ROTARY COMPRESSOR
COMPRESSOR
ACCUMULATOR
TOP CAP
THERMOSTAT
(S173)
ROTARY
COMPRESSION
CHAMBER
COMPRESSOR
MOTOR
CUTAWAY OF TYPICAL ROTARY
COMPRESSOR (NOT ACTUAL
EL23XCV COMPRESSOR)
FIGURE 31. EL23XCV Rotary Compressor Detail (All Models except EL23XCV-060)
