Lennox EL296DFE Series Installation Instructions

Page 58
Blower Data
EL296DF090XE48C PERFORMANCE (Less Filter)
External
Static
Pressure
in. w.g.
Air Volume / Watts at Various Blower Speeds
High
(Black)
Medium-High
(Brown)
Medium
(Blue)
Medium-Low
(Yellow)
Low
(Red)
cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts
0.00 1765 395 1565 265 1410 210 1290 175 1180 135
0.10 1745 410 1510 280 1365 220 1265 185 1120 140
0.20 1685 425 1455 295 1310 235 1220 200 1080 150
0.30 1630 440 1415 310 1285 250 1165 210 1035 160
0.40 1620 450 1370 320 1245 255 1125 220 985 175
0.50 1570 465 1335 330 1185 265 1080 230 925 180
0.60 1540 470 1295 345 1145 280 1045 240 875 190
0.70 N/A N/A 1260 355 1110 295 990 255 825 200
0.80 N/A N/A 1210 370 1060 305 940 260 760 205
EL296DF110XE60C PERFORMANCE (Less Filter)
External
Static
Pressure
in. w.g.
Air Volume / Watts at Various Blower Speeds
High
(Black)
Medium-High
(Brown)
Medium
(Blue)
Medium-Low
(Yellow)
Low
(Red)
cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts
0.00 2285 640 1990 435 1805 330 1685 265 1480 195
0.10 2250 660 1965 450 1775 345 1630 280 1430 205
0.20 2185 675 1910 465 1720 360 1575 295 1360 215
0.30 2150 690 1850 485 1670 375 1525 310 1290 235
0.40 2085 710 1810 495 1605 395 1465 325 1255 245
0.50 2060 725 1765 515 1565 400 1420 335 1190 255
0.60 2005 745 1700 535 1510 420 1370 355 1160 270
0.70 1970 760 1665 550 1460 440 1325 370 1100 280
0.80 1910 775 1620 560 1420 450 1275 380 1045 295
