Lennox EL296DFE Series Installation Instructions

Page 57
Blower Data
EL296DF045XE36B PERFORMANCE (Less Filter)
External
Static
Pressure
in. w.g.
Air Volume / Watts at Various Blower Speeds
High
(Black)
Medium-High
(Brown)
Medium
(Blue)
Medium-Low
(Yellow)
Low
(Red)
cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts
0.00 1395 335 1290 250 1190 195 910 105 865 95
0.10 1375 350 1245 260 1140 205 875 110 815 100
0.20 1320 360 1215 265 1090 215 825 120 785 110
0.30 1285 365 1165 270 1065 225 795 130 735 115
0.40 1275 375 1150 285 1025 230 750 135 705 120
0.50 1230 385 1095 295 985 240 705 145 650 125
0.60 1185 380 1060 300 935 245 655 150 605 135
0.70 N/A N/A 1020 310 915 250 590 150 545 140
0.80 N/A N/A 980 315 860 255 555 160 485 140
EL296DF070XE48B PERFORMANCE (Less Filter)
External
Static
Pressure
in. w.g.
Air Volume / Watts at Various Blower Speeds
High
(Black)
Medium-High
(Brown)
Medium
(Blue)
Medium-Low
(Yellow)
Low
(Red)
cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts
0.00 1770 510 1550 340 1355 220 1255 180 1035 115
0.10 1720 520 1510 355 1315 230 1200 185 980 105
0.20 1705 535 1470 365 1265 245 1165 195 895 110
0.30 1665 540 1430 380 1235 250 1120 205 835 120
0.40 1605 555 1390 395 1185 260 1070 210 775 130
0.50 1585 565 1335 400 1155 275 1015 225 690 140
0.60 1540 565 1300 410 1100 290 970 235 625 145
0.70 N/A N/A 1260 420 1050 295 915 245 570 150
0.80 N/A N/A 1220 430 1015 305 865 255 520 155
