Lennox Fhm 150 Installation, Operating And Maintenance Guide

COMMISSIONNING REPORT
FLEXYII_WSHP-IOM-1307-E - 32 -
Site details
Controller
Model
Serial No
Refrigerant
………………………………….
……………….…………………
…………………………………
…………………………………
Site
Unit Ref
Installer
………………………………………
……………………………………....
………………………………………
(1) ROOF INSTALLATION
Sufficient Access OK
Yes No
Condensate drain fitted
Yes No
Roofcurb
OK Not OK
(2) CONNECTIONS CHECK
Phase check
Yes No
Voltage between Phases
1 / 2
……………….
2 / 3
……………….
1 / 3
……………….
(3) CLIMATIC CONFIGURATION CHECK
CLIMATIC 60 Configured according to the Options and Specifications:
Yes No
(4) SUPPLY BLOWER SECTION
Type :
Power displayed on plate:
Voltage displayed on plate:
Current displayed on plate:
KW
V
A
N°1
……………………
……………………
……………………
N°2
……………………
……………………
……………………
Fan Type :
Forward
Backward
Forward
Backward
Displayed Belt Length :
mm
……………………
……………………
Tension Checked:
Yes No
Yes No
Alignment Checked :
Yes No
Yes No
Motor Pulley Diameter: D
M
mm
……………………
……………………
Fan Pulley Diameter: D
P
mm …………………… ……………………
Fan Speed = Motor rpm x D
M
/ D
P
Averaged Measured Amps :
rpm
A
……………………
……………………
……………………
……………………
Shaft Mechanical Power (Refer to airflow balancing)
W
……………………
……………………
Operating point checked :
Yes No
Yes No
Estimated Airflow
m
3
/h
……………………
……………………
(5) AIRFLOW PRESS. SENSOR CHECK
Measured pressure drop (2332)……………………… mbar
Set Points Adjusted: Yes No
If Yes enter new values:
2333: ………… 2334: ………… 2335: …………
(6) EXTERNAL SENSOR CHECKS
Check electrical connections :
Yes No
Check and record temp. in menu 2211
Yes Non
100% Fresh Air
100% return Air
Supply Temperature
………………………..°C
………………………..°C
Return Temperature
………………………..°C
………………………..°C
Outdoor Temperature
………………………..°C
………………………..°C
Inlet Water Temp. (for Water Condensing) ………………………..°C ………………………..°C
Outlet Water Temp. (for Water Condensing) ………………………..°C ………………………..°C
(7) MIXING AIR DAMPERS CHECKS
Dampers open & close freely
OK
% Minimum FA: Power exhaust checked Enthalpy sensor(s) checked
