COMMISSIONNING REPORT
FLEXYII_WSHP-IOM-0909-E Page 6
Site details
Site
Unit Ref
Installer
………………………………………
……………………………………....
………………………………………
Controller
Model
Serial No
Refrigerant
………………………………….
……………….…………………
…………………………………
…………………………………
(1) ROOF INSTALLATION
Sufficient Access OK
Yes
No
Condensate drain fitted
Yes No
Roofcurb
OK Not OK
(2) CONNECTIONS CHECK
Phase check
Yes
No
Voltage between Phases
1 / 2
……………….
2 / 3
……………….
1 / 3
……………….
(3)CLIMATIC CONFIGURATION CHECK
CLIMATIC 50 Configured according to the Options and Specifications:
Yes
No
(4) SUPPLY BLOWER SECTION
Type :
Power displayed on plate:
Voltage displayed on plate:
Current displayed on plate:
KW
V
A
N°1
……………………
……………………
……………………
N°2
……………………
……………………
……………………
Fan Type : Forward
Backward
Forward
Backward
Displayed Belt Length : mm …………………… ……………………
Tension Checked: Yes No Yes No
Alignment Checked : Yes No Yes No
Motor Pulley Diameter: D
M
mm …………………… ……………………
Fan Pulley Diameter: D
P
mm …………………… ……………………
Fan Speed = Motor rpm x D
M
/ D
P
Averaged Measured Amps :
rpm
A
……………………
……………………
……………………
……………………
Shaft Mechanical Power (Refer to airflow balancing) W …………………… ……………………
Operating point checked : Yes No Yes No
Estimated Airflow
m
3
/h
…………………… ……………………
(5) AIRFLOW PRESS. SENSOR CHECK
Measured pressure drop…………………………… mbar
Set Points Adjusted: Yes
No
If Yes enter new values:
3410: ………… 3411: ………… 3412: …………
(6) EXTERNAL SENSOR CHECKS
Check and record temp. in menu 2110
Yes
Non
Check electrical connections :
Yes
No
100% Fresh Air 100% return Air
Supply Temperature ………………………..°C ………………………..°C
Return Temperature ………………………..°C ………………………..°C
Outdoor Temperature ………………………..°C ………………………..°C
Inlet Water Temp. (for Water Condensing) ………………………..°C ………………………..°C
Outlet Water Temp. (for Water Condensing) ………………………..°C ………………………..°C
(7) MIXING AIR DAMPERS CHECKS
Dampers open & close freely
OK
% Minimum FA: Power exhaust checked Enthalpy sensor(s) checked
Yes No ……………..% Yes No Yes No
To Next Page
