Lennox G23Q2-50 - G23(X) Orientation; G23(X) General Parts Orientation

3DJH 
FIGURE 1
G23(X) ORIENTATION
TOP PANEL
BURNER ACCESS PANEL
BLOWER ACCESS
DOOR
SureLight Control
(-5 and -6 models only)
MAKE-UP BOX ASSEMBLY
SUPPLY AIR OPENING
HEATING COMPARTMENT
BLOWER COMPARTMENT
FIGURE 2
G23(X) GENERAL PARTS ORIENTATION
COMBUSTION AIR BLOWER
COMBUSTION AIR BLOWER
PROVE (PRESSURE)
SWITCH
GAS VALVE
PRIMARY LIMIT
MANIFOLD
BURNERS
SUPPLY AIR BLOWER
BLOWER CAPACITOR
CONTROL BOX
BLOWER COMPARTMENT
HEATING COMPARTMENT
FLUE TRANSITION
BLOWER DOOR
INTERLOCK SWITCH
IGNITION CONTROL
(-1 through -4 models only)
SUPPLY AIR DUCT FLANGE
ROLLOUT SWITCH
CIRCUIT BREAKER
