Lennox G23Q2-50 - G23(X) Heat Exchange Assembly; Control Box

Page 8
FIGURE 3
G23(X) HEAT EXCHANGE ASSEMBLY
-5 and -6 G23X Models
FLAME SENSE ASSEMBLY
MANIFOLD AND GAS VALVE
ORIFICE
HEAT EXCHANGER
(Heat Train
Assembly)
CLAMSHELL
(Each Segment)
BURNER ASSEMBLY
FLUE COLLECTOR
BOX
FLUE BOX
GLASS FIBER GASKET
ORIFICE PLATE
(FLUE TRANSITION ASSEMBLY)
FLUE OUTLET
GLASS FIBER GASKET
UPPER VEST
PANEL
FLAME BAFFLES (NOx UNITS ONLY)
RIGHT MANIFOLD BRACKET
ROLLOUT BRACKET
MID VEST PANEL
PRIMARY LIMIT
PRIMARY LIMIT
ALTERNATE STYLE
MANIFOLD END PLUG
ROLLOUT SWITCH
LEFT MANIFOLD BRACKET
COMBUSTION AIR BLOWER
TOP CAP
GLASS FIBER
GASKET
COMBUSTION BLOWER
GLASS FIBER GASKET
F
I
G
U
R
E
4
CONTROL BOX
(-1 through -4 G23X models)
BCC CONTROL
TRANSFORMER
DOOR INTERLOCK
SWITCH
LOW VOLTAGE STRIP
CIRCUIT BREAKER
F
I
G
U
R
E
5
CONTROL BOX
(-5 and -6 G23X models))
DOOR INTERLOCK
SWITCH
TRANSFORMER
LOW VOLTAGE STRIP
CIRCUIT BREAKER
SURELIGHT CONTROL
