Lennox G61MPVT User Manual

G61MPVT − 50hz / Page 5
SPECIFICATIONS
Gas
Hti
ModelNo. G61MPVT−36B−070 G61MPVT−60C−090 G61MPVT−60C−110 G61MPVT−60D−135
Heating
Performance
High
Fire
Input− Mj/h 69.6 92.8 116.1 139.3
Performance
Fire
Output− kW 17.9 23.7 29.0 35.7
Temperature rise range − C 25 − 41 22 − 39 28 − 44 36 − 53
Gas Manifold Pressure
(Natural Gas) − Pa
0.87 0.87 0.87 0.87
Low
Fire
Input− Mj/h 47.5 63.3 79.1 95.0
Fire
Output− kW 12.6 16.7 21.1 25.5
Temperature rise range − C 14 − 31 11 − 28 17 − 33 22 − 39
Gas Manifold Pressure
(Natural Gas) − kPa
0.42 0.42 0.42 0.42
Australian Gas Association
Energy Rating − Stars
5.3 5.3 5.3 5.3
Highstatic− Pa 200 200 200 200
Connections
in
Intake / Exhaust Pipe (PVC) 2 / 2 2 / 2 2 / 2 3 / 3
in.
Condensate Drain Trap
(PVC pipe) − i.d.
1/2 1/2 1/2 1/2
with field supplied (PVC cplg.) − o.d. 3/4 3/4 3/4 3/4
hose with hose clamp − i.d. x o.d. 1−1/4 x 1 1−1/4 x 1 1−1/4 x 1 1−1/4 x 1
GaspipesizeIPS 1/2 1/2 1/2 1/2
Indoor
Blower
Wheel nom. dia. x width −mm 203 x 508 292 x 508 292 x 508 292 x 508
Blower
Motoroutput − W 373 745 745 745
kW ofadd−oncooling 7.0 − 12.2 12.2 − 17.6 12.2 − 17.6 12.2 − 17.6
Air Volume Range − L/s 295 − 660 410 − 1020 350 − 1045 430 − 1035
ShippingData kg − 1 package 68 82 85 94
Electricalcharacteristics 240 volts − 50 hertz − 1 phase (less than 10 amps)
NOTE − Filters and provisions for mounting are not furnished and must be field provided.
OPTIONAL ACCESSORIES − MUST BE ORDERED EXTRA
B" Width Models C" Width Models D" Width Models
CABINET ACCESSORIES
Down−Flow Combustible Floor Base 11M60 11M61 11M62
CONDENSATE DRAIN KITS
Condensate Trap Alternate Location Kit − Up−Flow Only 76M20 76M20 − − −
CONTROLS
TERMINATION KITS − See Installation Instructions for specific venting information.
Concentric Termination Kits − Direct Vent
Applications Onl
50 mm (2 in.) 71M80 69M29 − − −
Applications Only
80 mm (3 in.) − − − 60L46 60L46
GAS HEAT ACCESSORIES
Input
High Altitude Pressure Switch Kit
ORDER TWO EACH
LPG/Propane Kit LPG/Propane to
Natural Gas Kit
Input
611 − 1372 m 0 − 610 m 611 − 1372 m 0 − 610 m 611−1372 m
−070 56M23 59M13 59M13 59M87 59M87
−090 56M23 59M13 59M13 59M87 59M87
−110 75M22 59M13 59M13 59M87 59M87
−135 Not allowed 59M13 Not allowed 59M87 Not allowed
