Lennox KGA Series User Manual

Page 11
BLOWER DATA
CEILING DIFFUSERS AIR RESISTANCE - in. w.g.
RTD11 Step-Down Diffuser
FD11 Flush
Diffuser
Unit Size
Air Volume
cfm
2 Ends Open
1 Side, 2 Ends
Open
All Ends & Sides
Open
092 Models
2400 0.21 0.18 0.15 0.14
2600 0.24 0.21 0.18 0.17
2800 0.27 0.24 0.21 0.20
3000 0.32 0.29 0.25 0.25
3200 0.41 0.37 0.32 0.31
3400 0.50 0.45 0.39 0.37
3600 0.61 0.54 0.48 0.44
3800 0.73 0.63 0.57 0.51
102 & 120 Models
3600 0.36 0.28 0.23 0.15
3800 0.40 0.32 0.26 0.18
4000 0.44 0.36 0.29 0.21
4200 0.49 0.40 0.33 0.24
4400 0.54 0.44 0.37 0.27
4600 0.60 0.49 0.42 0.31
4800 0.65 0.53 0.46 0.35
5000 0.69 0.58 0.50 0.39
5200 0.75 0.62 0.54 0.43
150 Models
4200 0.22 0.19 0.16 0.10
4400 0.28 0.24 0.20 0.12
4600 0.34 0.29 0.24 0.15
4800 0.40 0.34 0.29 0.19
5000 0.46 0.39 0.34 0.23
5200 0.52 0.44 0.39 0.27
5400 0.58 0.49 0.43 0.31
5600 0.64 0.54 0.47 0.35
5800 0.70 0.59 0.51 0.39
CEILING DIFFUSER AIR THROW DATA
Model No.
Air Volume
1
Effective Throw Range
RTD11 Step-Down FD11 Flush
cfm ft. ft.
092 Models
2600 24 - 29 19 - 24
2800 25 - 30 20 - 28
3000 27 - 33 21 - 29
3200 28 - 35 22 - 29
3400 30 - 37 22 - 30
102, 120
Models
3600 25 - 33 22 - 29
3800 27 - 35 22 - 30
4000 29- 37 24 - 33
4200 32 - 40 26 - 35
4400 34 - 42 28 - 37
150 Models
5600 39 - 49 28 - 37
5800 42 - 51 29 - 38
6000 44 - 54 40 - 50
6200 45 - 55 42 - 51
6400 46 - 55 43 - 52
6600 47 - 56 45 - 56
1
Throw is the horizontal or vertical distance an air stream travels on leaving the outlet or diffuser
before the maximum velocity is reduced to 50 ft. per minute. Four sides open.
