SPECIFICATIONS
General Data Nominal Tonnage 7.5 Ton 8.5 Ton 10 Ton 12.5 Ton
Model Number KGA092S4B KGA102S4B KGA120S4B KGA150S4B
Efciency Type Standard Standard Standard Standard
Blower Type Constant Air
Volume CAV
Constant Air
Volume CAV
Constant Air
Volume CAV
Constant Air
Volume CAV
Cooling
Performance
Gross Cooling Capacity - Btuh 88,900 100,500 119,600 144,800
1
Net Cooling Capacity - Btuh 86,000 97,000 115,000 138,000
AHRI Rated Air Flow - cfm 3,000 3,400 3,800 4,300
Total Unit Power - kW 7.8 8.8 10.4 12.8
1
EER (Btuh/Watt) 11 11 11 10.8
2
IEER (Btuh/Watt) 11.2 11.2 11.2 11
Refrigerant Type R-410A R-410A R-410A R-410A
Refrigerant
Charge
Furnished
Circuit 1 7 lbs. 8 oz. 8 lbs. 8 oz. 10 lbs. 0 oz. 14 lbs. 0 oz.
Circuit 2 7 lbs. 0 oz. 8 lbs. 8 oz. 10 lbs. 0 oz. 12 lbs. 0 oz.
Gas Heating Options Available - See page
6
Standard (2 stage), Medium (2 Stage), High (2 Stage)
Compressor Type (number) Scroll (2) Scroll (2) Scroll (2) Scroll (2)
Outdoor
Coils
Net face area (total) - sq. ft. 20.42 24.5 28.0 28.0
Tube diameter - in. 3/8 3/8 3/8 3/8
Number of rows 2 2 2 3
Fins per inch 20 20 20 20
Outdoor
Coil Fans
Motor - (No.) hp (2) 1/3 (2) 1/3 (2) 1/3 (2) 1/2
Motor rpm 1075 1075 1075 1075
Total Motor watts 670 670 670 830
Diameter - (No.) in. (2) 24 (2) 24 (2) 24 (2) 24
Number of blades 3 3 3 3
Total Air volume - cfm 7200 7400 7800 8,800
Indoor
Coils
Net face area (total) - sq. ft. 12.78 12.78 12.78 13.54
Tube diameter - in. 3/8 3/8 3/8 3/8
Number of rows 2 2 3 4
Fins per inch 14 14 14 14
Drain connection - Number
and size
(1) 1 in. NPT coupling
Expansion device type Balance port TXV, removable head
3
Indoor
Blower and
Drive
Selection
Nominal motor output 2 hp, 3 hp, 5 hp
Maximum usable motor output
(US Only)
2.3 hp, 3.45 hp, 5.75 hp
Motor - Drive kit number 2 hp
4
Kit 1 590-890 rpm
Kit 2 800-1105 rpm
Kit 3 795-1195 rpm
3 hp
Kit 4 730-970 rpm
Kit 5 940-1200 rpm
Kit 6 1015-1300 rpm
5 hp
Kit 10 900-1135 rpm
Kit 11 1040-1315 rpm
Kit 12 1125-1425 rpm
Blower wheel nominal
diameter x width - in.
(1) 15 X 15 (1) 15 X 15 (1) 15 X 15 (1) 15 X 15
Filters Type of lter Disposable
Number and size - in. (4) 20 x 25 x 2
Electrical characteristics 208/230V, 460V or 575V - 60 hertz - 3 phase
NOTE - Net capacity includes evaporator blower motor heat deduction. Gross capacity does not include evaporator blower motor heat deduction.
1
Certied in accordance with the ULE certication program, which is based on AHRI Standard 340/360; 95°F outdoor air temperature and 80°F db/67°F wb entering
evaporator air; minimum external duct static pressure.
2
Integrated Energy Efciency Ratio certied and tested according to AHRI Standard 340/360..
3
Using total air volume and system static pressure requirements determine from blower performance tables rpm and motor output required. Maximum usable output of
motors furnished are shown. In Canada, nominal motor output is also maximum usable motor output. If motors of comparable output are used, be sure to keep within
the service factor limitations outlined on the motor nameplate.
4
Standard motor and drive kit furnished with unit.
