Lennox KGA Series User Manual

Page 14
KGA PARTS ARRANGEMENT
FIGURE 1
EVAPORATOR
COIL
CONDENSER
FANS
CONDENSER
COIL
COMPRESSORS
CONDENSATE
DRAIN
FILTERS
(FOUR - 20 X 25 X 2”)
ECONOMIZER
(OPTIONAL)
BLOWER
MOTOR
GAS VALVE
BURNERS
COMBUSTION
AIR INDUCER
DISCONNECT /
CIRCUIT BREAKER
(FACTORY- OR FIELD-
INSTALLED OPTION)
BLOWER
KGA CONTROL BOX - Y, G, J-VOLT UNITS
FIGURE 2
K1
K2 K3
S42
K65
K10
K125
T1
T3
KGA CONTROL BOX - M VOLT CE UNITS
FIGURE 3
K1 K2 K3
S42
S176 S177
K65
K10
T1
