OPTIONS / ACCESSORIES
Item Catalog
No.
024 030 036 048 060 072
COOLING SYSTEM
Condensate Drain Trap PVC - C1TRAP20AD2 76W26 X X X X X X
Copper - C1TRAP10AD2 76W27 X X X X X X
Drain Pan Overow Switch K1SNSR71AB1 74W42 X X X X X X
Low Ambient Kit K1SNSR13A-1 41W34 X X X X X X
Efciency Standard O O O O O O
Refrigerant Type R-410A O O O O O O
Blower - SUPPLY AIR
Motors Direct Drive - 0.25 hp O O
Direct Drive - 0.5 hp O O
Belt Drive - 1.5 hp Standard Efciency O O O O
1
Belt Drive - 2 hp Standard Efciency O O O O
Drive Kits
See Blower Data Tables
for selection
Kit A01 - T1DRKT001-1 - 673-1010 rpm Factory O
Kit A02 - T1DRKT002-1 - 745-1117 rpm Factory O
Kit A03 - T1DRKT003-1 - 833-1250 rpm Factory O
Kit A04 - T1DRKT004-1 - 968-1340 rpm Factory O
Kit A05 - T1DRKT005-1 - 897-1346 rpm Factory O
Kit A06 - T1DRKT006-1 - 1071-1429 rpm Factory O
Kit A07 - T1DRKT007-1 - 1212-1548 rpm Factory O
Kit A08 - T1DRKT008-1 - 1193-1591 rpm Factory O
CABINET
Coil Guards T1GARD20A-1 17W87 X X X X
T1GARD20N-1 17W88 X
K1GARD20AP1 53W21 X
Corrosion Protection O O O O O O
Hail Guards T1GARD10A-1 17W89 X X X X
T1GARD10N-1 17W90 X
K1GARD10AP1 53W22 X
Hinged Access Panels O O O O O O
CONTROLS
Smoke Detector - Supply or Return (Power
board and one sensor)
C1SNSR44AP1 53W78 X X X X X X
Smoke Detector - Supply and Return
(Power board and two sensors)
C1SNSR43AP1 53W79 X X X X X X
Indoor Air Quality
Indoor Air Quality (Co
2
) Sensors
Sensor - Wall-mount, off-white plastic cover
with LCD display
C0SNSR50AS1L 77N39 X X X X X X
Sensor - Wall-mount, black plastic case, no
display, rated for plenum mounting
C0SNSR53AE1L 87N54 X X X X X X
CO
2
Sensor Duct Mounting Kit - for
downow applications
C0MISC19AE1- 85L43 X X X X X X
Aspiration Box - for duct mounting non-
plenum rated CO2 sensor (77N39)
C0MISC16AE1- 90N43 X X X X X X
UVC Germicidal Lamps
2
Healthy Climate
®
UVC Light Kit
(208/230v-1ph)
E1UVCL10AN1 50W90 X X X X X X
NOTE - The catalog and model numbers that appear here are for ordering eld installed accessories only.
OX - Field Installed or Congure to Order (factory installed)
O - Congure to Order (Factory Installed)
X - Field Installed
1
2 hp blower motor is not available for 208/230V-1ph applications.
2
Lamps operate on 110-230V single-phase power supply. Step-down transformer may be ordered separately for 460V and 575V units. Alternately, 110V power supply
may be used to directly power the UVC ballast(s).
