OPTIONS / ACCESSORIES
Item Catalog
No.
024 030 036 048 060 072
OUTDOOR AIR
Outdoor Air Dampers
Damper Section - Manual,
Includes Outdoor Air Hood
T1DAMP11A-1 16W88 X X X X
T1DAMP11N-1 16W91 X X
Damper Motorized Kit
Order Manual Outdoor Air Damper Separately
T1DAMP21AN1 16W92 X X X X X X
POWER EXHAUST FAN
Standard Static 208/230V-1 or 3 ph - T1PWRE10A-1P 17W39 X X
460V-3ph - T1PWRE10A-1G 17W40 X X
575V-3ph - T1PWRE10A-1J 17W41 X X
208/230V-1 or 3 ph - T1PWRE10N-1P 17W42 X X
460V-3ph - T1PWRE10N-1G 17W43 X X
575V-3ph - T1PWRE10N-1J 17W44 X X
CEILING DIFFUSERS
Step-Down - Order one RTD9-65-R 27G87 X X X X X
RTD11-95 29G04 X
(Canada Only) RTD11-95S 13K61 X
Flush - Order one FD9-65-R 27G86 X X X X X
FD11-95 29G08 X
(Canada Only) FD11-95S 13K56 X
Transitions (Supply and Return) - Order one T1TRAN10AN1 17W53 X X X X X
T1TRAN20N-1 17W54 X
ROOF CURBS - downFlow
Cliplock
8 in. height T1CURB23AN1 16W93 X X X X X
1
X
K1CURB23AP1 52W20 X
14 in. height T1CURB20AN1 16W94 X X X X X
1
X
K1CURB20AP1 52W21 X
18 in. height T1CURB21AN1 16W95 X X X X X
1
X
K1CURB21AP1 52W22 X
24 in. height T1CURB22AN1 16W96 X X X X X
1
X
K1CURB22AP1 52W23 X
Hinged
8 in. height T1CURB30AN1 17W46 X X X X X
1
X
K1CURB30AP1 52W17 X
18 in. height T1CURB32AN1 17W47 X X X X X
1
X
K1CURB32AP1 52W18 X
24 in. height T1CURB33AN1 17W48 X X X X X
1
X
K1CURB33AP1 52W19 X
Standard
14 in. height T1CURB10AN1 13W27 X X X X X
1
X
K1CURB10AP1 52W24 X
Adjustable Pitched Curb
14 in. height C1CURB55AT1 43W27 X X X X X
1
X
NOTE - The catalog and model numbers that appear here are for ordering eld installed accessories only.
X - Field Installed.
1
072 models will t smaller roof curbs with overhang. See dimension drawing.
